Southbend P24C-TT Platinum Heavy Duty Range

Platinum Heavy Duty Range, gas, 24", griddle, 1" thick plate, thermostatic controls, battery spark ignition, cabinet base, stainless steel front sides, rear, exterior bottom & 6" adjustable legs, 64,000 BTU, cCSAus, CSA Flame, CSA Star, NSF

A griddle and a cabinet base in one, this 24" heavy-duty commercial gas range is a great addition to any kitchen looking to add a reliable cooking station. The griddle is powered by four (2) burners with two (2) thermostatic control knobs that allow you to find the precise temperature for each recipe. The griddle plate has a thickness of 1", which allows it to retain heat well and cut down recovery and preheat time in between cooking sessions. There are splash guards at the sides and rear to protect nearby equipment and surfaces from spills and splatters. The front of the griddle has a 9.25" deep rail that offers an extra work surface.

This commercial range is mainly stainless steel including the front, sides, rear, exterior bottom, and 6" legs, which you can adjust to different heights if you have uneven flooring. The lining and the burner box are fully insulated to keep the operation efficient and temperatures consistent. A removable stainless steel drawer catches grease coming from the cooking surface so you can easily dispose of it. A 5" high stainless steel flue riser drives heat and smoke emanating from the griddle away from users and into the vent.

This heavy-duty range meets all cCSAus, CSA Flame, CSA Star, and NSF standards.

CKitchen is your top source for premium-quality restaurant and heavy-duty ranges and commercial cooking equipment. Upgrade your kitchen with us today!

Standard Features

• 24" wide sectional range with full-width griddle available with a cabinet base
• Four 16,000 BTU NAT (14,000 BTU LP) burners with two control knobs
• Electronic pilot ignition - Piezo
• 1" thick griddle plate with side and rear splashers
• 9-1/4" deep front rail
• Removable stainless steel grease drawer
• Stainless steel front, sides, rear and exterior bottom
• Fully insulated lining and burner box
• 1-1/4" front gas manifold and 1" rear gas connection
• 5" high stainless steel flue riser
• Free battery-design assistance
• (1) year limited parts and labor warranty
• More cooking equipment available

Thermostatic Griddle Models

• “Insta-On” thermostatic control of griddle surface temperature in the range 180°F to 400°F

Cabinet-Base Models

• Stainless steel cabinet with removable doors that open from the center

Options & Accessories

• External pressure regulator
• Front rail options:
  • Cutouts in front rail for sauce pans
  • 7-1/4" deep front rail (to match old style sectional)
  • Square belly bar mounted on 7-1/4" deep front rail
• Casters (front two casters lock)
• Cable restraint kit (to restrict movement when on casters)
• 24" or 36" high flue riser
• Shelves on flue riser (one on 24" flue riser, one or two on 36" flue riser, 10" deep)
• Tray or tubular shelves (12" deep)
• Open-frame base with casters for future battery
• Extra-deep rear-extending flue riser
• Removable shelf inside cabinet
• Grooved griddle surface
• Chrome griddle surface

Construction

• Exterior Finish: Front, sides, rear and exterior bottom constructed of #3 polished 430 and 304 stainless steel.
• Range: 24"-wide front-manifold sectional range includes full-width 64,000 BTU NAT (56,000 BTU LP) griddle with 1" thick stainless steel surface, side and rear splashers and grease drawer.
• Front Rail: 9-1/4" deep front rail.
• Flue Riser: 5" high stainless steel flue riser
• Battery: Unit can be in any position in a battery. If the unit is at the end of the battery, the end side will be solid (rather than have a cover plate over the end of the front manifold).
• Legs: 6" stainless steel adjustable legs standard.
• Model 24C: Stainless steel cabinet base with two removable doors that open from the center.
