Southbend P12N-B Platinum Heavy Duty Range
Calculate
- Please see specification sheet for installation clearance requirements
Southbend P12N-B Specifications
| BTU | 35,000 BTU |
|---|---|
| Number of Burners | 1 - 2 |
| Total BTU | 16000 - 130000 |
| Burner Type | 35,000 BTU open burners |
| Burner Style | Grates |
| Installation Type | Modular |
| Range Base Style | Modular Base |
| Brand | Southbend |
| Certifications | NSF |
| Control Type | Manual |
| Heat | Gas |
| Number of Ovens | None |
| Width (in) | 12 |
| Height (in) | 13.5 |
| Depth (in) | 38.75 |
| Weight | 130.00 |
Additional Information on Southbend P12N-B
A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Southbend P12N-B Certifications
NSF
This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.
Southbend P12N-B Description
This heavy-duty commercial gas range allows you to conveniently add two (2) powerful 35,000 BTU open burners on your countertop or chef base to increase your production capacity without using additional floor space. The burners come with manual controls for easy operation. Designed to stand up to the rigors of daily use, this commercial range is stainless steel on the front and sides, rear and exterior bottom, and 6" legs, which can be adjusted to fit uneven flooring. To keep the temperature consistent and the operation safe, the lining and the burner box are fully insulated. The front of the cooktop has a 9.25" deep rail that you can use as additional space while the drip tray can be removed for easy maintenance. The 5" high stainless steel flue riser ensures the heat and gases that come from the cooktop are redirected to the hood and away from the user.
This heavy-duty range comes with CSA Flame, CSA Star, and cCSAus certifications. Check out our full selection of premium-quality restaurant and heavy-duty ranges and commercial cooking equipment to complete your kitchen.
Standard Features:
- Removable drip tray
- 9-1/4" deep front rail
- Free battery-design assistance
- 5" high stainless steel flue riser
- Removable, welded steel top grate
- Fully insulated lining and burner box
- Stainless steel front, sides, rear, and exterior bottom
- 1-1/4" front gas manifold and 1" rear gas connection
- Two 35,000 BTU NAT (35,000 BTU LP) patented clog-free burners (lifetime warranty)
- 12" wide sectional range with two open-top burners available with a cabinet base or as a modular unit (for mounting on countertop, refrigerated or freezer base).
- Stainless steel cabinet with a removable door that can hinge on the right or the left.
- Battery spark ignition
- 24" or 36" high flue riser
- External pressure regulator
- Removable, cast iron grate top
- Casters (front two casters lock)
- Removable shelf inside cabinet
- Tray or tubular shelves (12" deep)
- Extra-deep rear-extending flue riser
- Open-frame base with casters for future battery
- Cable restraint kit (to restrict movement when on casters)
- Shelves on flue riser (one on 24" flue riser, one or two on 36" flue riser, 10" deep)
- Front rail options:
- Cutouts in front rail for sauce pans
- 7-1/4" deep front rail (to match old style sectional)
- Square belly bar mounted on 7-1/4" deep front rail
