Frymaster FPRE417TC (4) 50 lb. Full Frypots Electric Floor Fryer with CM3.5 Controls and Built-In Filter System, 208/240 Volts

MPN#: FPRE417TC
Free Freight?
Quick Ship
Energy Star Energy Star ?
Products with Energy Star certification are designed to be more energy-efficient to maximize savings.
$59,426.33 /

Contact us for details!!!

$59,426.33 /
or enjoy small payments $1,277.07/mo.
Lease Payment Calculate
Product Protection
Product Protection
Starting at
Reward Points
Reward Points
You will earn 59426
Additional Options and Accessories are Available.
Please call:
1 (800) 555-0666

Frymaster FPRE417TC Specifications

Number of Fry Pots4
Filtration SystemBuilt-In Filter System
Control TypeCM3.5
CabinetEnamel
Plug TypeHardwire
Burner StyleOpen Pot
BrandFrymaster
Energy EfficiencyEnergy Star
CertificationscULus
Capacity(4) 50 lb. Frypots
Voltage208/240 Volts
Width (in)62.63
Height (in)45.38
Depth (in)31
Weight780.00

Frymaster FPRE417TC Certifications

cULus

cULus

UL (Underwriters Laboratories) approval for the US and Canada

NSF

NSF

This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.

Frymaster FPRE417TC Description

Frymaster® Fryer Battery, electric, hi-efficiency, (4) 50 lb. capacity each, built-in filtration, open frypot design, CM3.5 controller with TRIAC controls, automatic melt cycle, boil out temperature controls, includes: rack-type basket supports, basket hangers & twin baskets, stainless steel frypots, doors, & cabinets, (4) 17kW, cULus, NSF, TUV, ENERGY STAR®, Enerlogic®

The Frymaster FPRE417TC electric multiple-battery fryer with four (4) 50-lb stainless steel 17 kW frypots and CM3.5 controller with TRIAC controls is a suitable companion for businesses looking for high-efficiency cooking equipment for large-production needs. The frying area for each frypot measures 14"  by 15.5" and with twin baskets in tow, this fryer can handle a varied menu easily. The enamel cabinet and stainless steel door make this commercial deep fryer a tough companion in busy and intense operations!

Easy to operate, easier to own

The low-watt flat-bar heating elements, CM3.5 controller, and an RTD 1° compensating temperature probe all work together to give you accurate temperature readings and prolong the life of the oil! This fryer includes a melt cycle feature and boil-out temperature control and even automatically adjusts cooking time based on load size.

Effortless cleaning

The heating elements have a swing-up, self-standing design so they can be lifted up during cleaning. Sediment goes to the spacious cold zone from which the 1.25" IPS ball-type drain valve flushes it all out. The sloped bottom of the drain pan ensures every piece of debris and crumbs come out. This commercial fryer even includes a drain safety switch and casters for added mobility!

Money-saving filtration system

The important process of filtration won't take you longer than five minutes on this deep fryer. The large filter pan is at a convenient location for cleaning and clearance requirements while the drain is super wide so the oil moves freely. This filtration system is located right inside the fryer cabinet to save space and it can filter 6 Commercial Deep Fryers in one battery.

The Frymaster FPRE417TC is also an Enerlogic fryer with cULus and UL certifications for assured quality and safe commercial use. The unit ships with twin baskets, a filter starter kit, rack-type basket support, and a basket hanger. If you want to customize your unit, you can easily do so by selecting parts and accessories available below.

Fryer Standard Features:
  • Casters
  • Rear oil flush
  • CM3.5 controller
  • 2 twin fry baskets
  • Drain safety switch
  • 14 kw, 17 kw or 22 kw input
  • Melt cycle and boil out mode
  • Stainless steel frypot, door and cabinet
  • Open frypot (full or split) design - easy to clean
  • Robust, RTD 1° compensating temperature probe
  • Proprietary, self-standing, swing-up, flat-bar, low watt density, long-life heating *elements
  • Deep cold zone with 1-1/4” (3.2 cm) IPS, full-port, ball-type drain valve for full frypots; 1” IPS fullport ball-type drain valve for split frypots
  • Full Frypot
    • 14/17/22 kw
    • Frying area 14” X 15-1/2”
    • 50-lb. (25 liter) oil capacity
  • Split Frypot
    • 7/8.5/11 kw
    • 25-lb. (12 liter) oil capacity
    • Frying area 6-3/4” x 15-1/2”
Filter Standard Features
  • Casters
  • 4 GPM pump
  • Filter starter kit
  • 1/3 H.P. filter motor
  • Stainless crumb catcher
  • Filters up to 6 fryers in one battery
  • Large 3-inch round drain allows oil to drain freely
  • Large capacity filter pan removes easily for cleaning
  • Filter pan designed on rails to clear floormats for easy cleaning
  • Sloped drain pan leaves minimal residue oil behind after filtering
  • 1-1/4” (3.2 cm) drain valve standard on full frypots. 1” (2.5 cm) drain valve standard on split frypots
  • Filter cycle is complete from start to finish in less than 5 minutes, while other frypots in the system are in use
  • Space-saving filter which fits inside fryer cabinet housing two full or qualifying split frypots in two left most cabinets of the battery
Options & Accessories
  • Full basket
  • Split frypots
  • Crisper tray
  • Triplet basket
  • Splash shield
  • Sediment tray
  • Frypot cover(s)
  • Spreader cabinet - must fit within a 6-cabinet fryer battery
  • RE Controllers: Digital or SMART4U® 3000. RETC - no controller options
  • Automatic basket lifts (units with basket lifts require CM3.5 or 3000 controller)
  • External oil discharge - available on built-in filter batteries of 2 or more frypots or a frypot/spreader - must specify front or rear connection

Options for Frymaster FPRE417TC

External oil discharge options
Frypot
Start-up program
Installation/Disposal
Spreader cabinet
Legs & casters
Standard warranty
What is included
  • Manufacturer's note: Note: Prices listed are for within the USA only. Please contact the factory for pricing if quoting outside of the USA
  • Voltage (filter): 120v/60/1-ph, 8 amps with cord & plug, for filter unit
