Delfield N8745-DESP Drop-In Hot Food Well Unit
MPN#: N8745-DESP
Free Freight?
Quick Ship
$4,724.00 /
Contact us for details
Calculate
Product Protection
Starting at
Delfield N8745-DESP Specifications
| Construction | Stainless and Galvanized Steel |
|---|---|
| Brand | Delfield |
| Certifications | CE |
| Width (in) | 45.63 |
| Height (in) | 9.5 |
| Depth (in) | 26 |
| Weight | 134 |
Additional Information on Delfield N8745-DESP
A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Delfield N8745-DESP Certifications
CE
The product complies with the essential requirements of the relevant European health, safety and environmental protection legislations.
NSF
This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.
UL
UL has tested representative samples of this product and determined that the product meets specific, defined requirements.
Delfield N8745-DESP Description
Drop-In Hot Food Well Unit, Electric, individual pans, wet/dry type with drain & manifold, 3-pan size for 12" x 20" pan, individual digital temperature controls, stainless steel top & wells, galvanized exterior body, (44-5/8" x 25" cutout required), UL, NSF, cUL, CE
Drop-In Hot Food Well Unit, electric, individual pans, wet/dry type with drain & manifold, 3-pan size for 12" x 20" pan, individual digital temperature controls, stainless steel top & wells, galvanized exterior body, (44-5/8" x 25" cutout required), UL, NSF, cUL, CE
Standard Features:
- Wet and dry operation
- Galvanized exterior body
- Energy Saving Power wells
- Must be hard wired in the field
- Non-marring press fit top gasket
- One year parts and labor warranty
- Standard 1/2” stainless steel drain(s)
- Energy efficient 500 watt heat-pad per well
- Top is constructed of 18-gauge stainless steel
- Wells depressed slightly into the top to hold in condensation
- Unit shall be insulated on the bottom and all sides with 1” of fiberglass
- Flush mounted die stamped drawn 12” x 20” individual 20-gauge wells
- 11.87” x 19.87” single hot food wells are manifolded together standard to one main gate valve
- Individual digital temperature controls standard wired to one main control panel with 4’ of conduit and wire. Field install control panel at location
Options & Accessories:
- Autofill option
- Fill faucet option
- Telescoping covers
- Adapter plates and bars
- Omit drains and manifold
- 3 phase electrical system
- 240 volt, 50 cycle electrical system
- Single- or double-service flip-up sneeze guards
- Inclusion of this option will alter electrical specifications of the unit
Specifications:
Top shall be one-piece 18-gauge stainless steel, with 0.65" (2cm) overhang around perimeter and die-stamped 19.87" x 11.87" (50cm x 30cm) openings with depressed edges. Formed well below each opening shall be 6.25" (16cm) deep. Each well shall be equipped with a 0.5" female N.P.T. drain located in right rear corner. All drains manifold to a 0.5" gate valve at the left. Exterior housing shall be 20-gauge galvanized steel. Unit shall be insulated on sides, bottom and between wells with 1.00" (2.5cm) fiberglass. Energy Saving Power wells (ESP) provided with individual solid state digital temperature controls wired to one main control panel with 4’ of conduit and wire. Each well is individually equipped with a 500 watt heated pad attached to bottom and sides of well. Unit shall have a three-wire electrical junction box to allow hard-wiring at installation. Electrical connections are 208-230V or 240V.
Delfield N8745-DESP Accessories
