Beverage Air UCFD60AHC-2 60'' 2 Section Undercounter Freezer with 1 Right Hinged Solid Door 2 Drawers and Front Breathing Compressor

SKU#: UCFD60AHC-2
Made in USA
Free Freight?
Quick Ship
$5,959.98
$5,200.69
or enjoy small payments $111.76/mo.
Lease Payment Calculate
Product Protection
Product Protection
Starting at
Reward Points
Reward Points
You will earn 5960
  • 2023 model, meets the newest EPA and DOE codes.

Beverage Air UCFD60AHC-2 Specifications

Access TypeDoors and Drawers
Compressor StyleFront Breathing
Hinge LocationRight
Door HingeRight Hinged
BrandBeverage Air
Refrigerant TypeR-290
Number of Doors1
Made inUSA
CertificationscULus
Refrigeration SystemSelf-contained
Capacity11 - 30 cu. ft.
Door TypeSolid
Number of Drawers2
Sections2
StyleCounter Height
Voltage115 Volts
Width (in)60
Height (in)34.5
Depth (in)32
Weight265.00

Additional Information on Beverage Air UCFD60AHC-2

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

Beverage Air UCFD60AHC-2 Certifications

cULus

cULus

UL (Underwriters Laboratories) approval for the US and Canada

UL

UL

UL has tested representative samples of this product and determined that the product meets specific, defined requirements.

UL EPH

UL EPH

Certifies that the goods conform to public health and environmental quality compatibility requirements.

UL EPH Classified

UL EPH Classified

This product complies with UL EPH standards and meets ANSI/NSF requirements.

UL-Sanitation

UL-Sanitation

This item has been tested and meets the sanitation hazard standards imposed by the Underwriters Laboratories (UL).

Beverage Air UCFD60AHC-2 Description

Undercounter Freezer, two-section, 60"W, 17.1 cu. ft., (2) drawers (1) door, (2) shelves, stainless steel exterior & top, aluminum interior, rear-mounted self-contained refrigeration, R290 Hydrocarbon refrigerant, 1/2 HP, cULus, UL EPH Classified, UL-Sanitation, MADE IN USA

A versatile freezer like the UCFD60AHC-2 Undercounter Freezer from Beverage Air provides users with options with its two drawers and a single reach-in section. This configuration gives users quick access to frozen items while taking up very little room. The freezer offers a total of 14.39 cu. ft. of space.

Each drawer features a painted aluminum handle for easy access. Stainless steel drawer frames provide a solid platform while telescoping slides make sure the drawers slide effortlessly.  In a busy commercial environment, you can expect the drawers to be accessed quite aggressively. To make sure drawers don’t pull out completely and spill items onto the floor, the drawer slides feature a locking mechanism. The drawers maintain a tight seal to keep in the cold thanks to magnetic gaskets.

This unit features a self-closing door making it convenient to access items quickly while making sure the door is never left ajar. Two epoxy-coated shelves make the most out of the available space. To make accessing multiple items as simple as possible the door can be opened to 120˚ to keep it open allowing users to use both hands. When the door is closed a magnetic gasket makes sure that an airtight seal is maintained.

1868 BTU/hr of cooling is provided by the refrigeration system at the bottom of this unit with a ½ HP compressor. To keep items frozen, the temperature inside is maintained below 0ºF by the full electronic controls. An epoxy-coated evaporator coil makes sure efficient cooling will be provided for many years with minimal service. This unit defrosts automatically with an electric system to reduce downtime while maintaining peak efficiency. To meet all environmental regulations R290 hydrocarbon refrigerant is used.

The unit conveniently comes with 6” casters from the factory, this allows it to be easily moved into and out of place. The front casters are locking which keeps it in place when it’s in use. Power is supplied to the unit with a factory wired 8-foot power cord with a NEMA 5-15P plug set to connect it to a standard outlet that provides 115v/60/1-ph power at 7.0 amps.

Beverage Air UCFD60AHC-2 60'' 2 Section Undercounter Freezer with 1 Right Hinged Solid Door 2 Drawers and Front Breathing Compressor

Undercounter Freezer, two-section, 60" W, 17.1 cu. ft., (2) drawers (1) door, (2) shelves, stainless steel exterior & top, aluminum interior, rear-mounted self-contained refrigeration, 6" casters, R290 Hydrocarbon refrigerant, 1/3 hp, UL, cUL, UL EPH, MADE IN USA

Standard Features:
  • Cabinet Construction
    • Full electronic control
    • Two epoxy-coated steel wire shelves
    • 6” Casters, two (2) with brakes standard
    • Easy door removal for service and cleaning
    • Painted aluminum door and drawer handle(s)
    • Freezer temperature is held at 0º F and below
    • Durable sub-top 1/2” insulated for added durability
    • Interior liner is made of corrosion resistant aluminum
    • Upper and Lower pull out drawers accommodate 6” deep pans
    • Magnetic gasket attached to each door and drawer for positive seal
    • Stainless steel drawer frames supported on telescoping drawer slides
    • Self-closing doors with 120˚ Stay-open feature, on cartridge style hinges
    • Stainless steel front, sides, top, door(s) and drawer(s), (galvanized back & bottom)
    • Drawer slides include locking mechanism that prevents drawer from being inadvertently pulled off cabinet
  • Refrigeration System
    • Epoxy coated evaporator coil
    • System is serviceable from rear
    • Automatic, non-electric evaporator
    • Refrigeration system uses R290 refrigerant to comply with all environmental concerns
  • Options & Accessories
    • 6” Legs
    • 3” Casters
    • Remote option
    • Food service pans
    • Low profile casters
    • Stainless steel interior
    • Stainless steel back and grille
    • Door and combination models available

Options for Beverage Air UCFD60AHC-2

Stainless steel interior
Legs & Casters
Stainless steel back
Refrigeration
What is included
  • Voltage: 115v/60/1-ph, 7.0 amps, cord with NEMA 5-15P
  • Warranty: 7 year parts & labor and 7 year compressor warranty (excludes maintenance items)
16 gauge top

Beverage Air UCFD60AHC-2 Accessories

Beverage Air 403-914D-01 Shelf 403-914D-01
$75.56
Beverage Air 705-397D-11 Cutting Board 705-397D-11
$250.65
Beverage Air 00C31-055A Legs 00C31-055A
$196.11
Beverage Air 403-721C Shelf 403-721C
$73.91
Beverage Air 403-169A Shelf clip 403-169A
$1.97
Beverage Air 705-397D-15 Cutting Board 705-397D-15
$2,270.92

Beverage Air UCFD60AHC-2 Parts

All Beverage Air UCFD60AHC-2 Parts
