Beverage Air BB48HC-1-FG-PT-B Refrigerated Pass-Thru Back Bar Open Food Rated

Refrigerated Pass-Thru Back Bar Open Food Rated Refrigerator, two-section, 48"W, 34" H, 13.6 cu. ft. capacity, (4) glass doors with locks, (4) epoxy coated steel shelves, (2) 1/2 barrel keg, LED interior lighting, galvanized sub top, black exterior finish, stainless steel interior, meets NSF-Standard 7 for open food container, right-mounted self-contained refrigeration, R290 Hydrocarbon refrigerant, 1/3 HP, cULus, UL EPH Classified, UL-Sanitation, Made in USA

If your bar needs reliable refrigeration and you want to provide customers with a clear view of beverages or products that are available the BB48HC-1-FG-PT-B Refrigerated Pass-Thru Back Bar Open Food Rated from Beverage Air is an excellent choice. This glass door pass-thru unit allows items to be seen and accessed from either side for convenience. The 13.6 cu. ft of food rated storage capacity this refrigerator offers can be used to store a pair of  ½ kegs.

The reach-in section features two epoxy-coated steel wire shelves to keep items organized and easy to access. To prevent the door from being left ajar the door is self-closing. The interior is made from stainless steel for easy cleaning and maintenance. This refrigerator is open food product certified. In a busy kitchen, users will often need to access multiple items from a refrigerator. To simplify this the doors have a stay-open feature. When the doors are closed magnetic gaskets make sure the seals are always airtight. Balanced forced-air refrigeration allows this back bar refrigerator to quickly and evenly cool items

On the side of this back bar refrigerator is a self-contained refrigeration system featuring a ⅓ HP compressor that puts out 1942 BTU/hr of cooling. The compressor can be located on either the left or right side of the unit to best fit your needs. The unit's epoxy-coated evaporator keeps the interior between 36ºF and 38ºF reliably with minimal maintenance while the fully electronic controls keep power consumption and stress on the refrigeration system to a minimum. The non-electric automatic defrost cycle keeps the unit running efficiently while keeping downtime to a minimum. R290 refrigerant is eco-friendly and provides efficient cooling while meeting all regulations.

Connecting this unit to a standard 115v/60/1-ph power outlet is simple with the factory wired 8’ power cable with a NEMA 5-15P plug set.

Never run short on storage space again when you install this top-of-the-line Beverage Air BB48HC-1-FG-PT-B Refrigerated Pass-Thru Back Bar Open Food Rated. This backbar storage cabinet is 34 inches tall, 48 inches wide, and 25 inches deep.

• BB Pass-Thru Glass Door
• Back Bar Refrigerator Open Food Rated Series
  • Food Rated models are certified for bottled beverages, packaged food, and open food.
  • Pass-thru back bar storage cabinets come in four basic, self-contained models up to 95” wide.
  • Handles project 1 3/4.” One size self-contained, end mount model (BB78E) and two remote models (BB58R and BB78R) complete the 27” base series of back bars.
  • Overall height is 37 1/4.” Depth is 27” from face of door to back of cabinet. Depth is 23 1/2” from face of door to back of cabinet on Shallow Depth models (BB48 & BB72).
• Cabinet Construction
  • Stainless exterior options available.
  • Glass doors are self-closing and include key locks.
  • Magnetic door gaskets provide positive door sealing.
  • Glass doors are field reversible with hinge kit accessory.
  • Equipped with 2” stainless steel top, BB48 and BB72 is optional.
  • Standard, cabinet exterior construction is made of a black steel finish.
  • Reinforced floor and door sills are made from heavy-duty stainless steel to provide long lasting service.
  • All stainless steel interior with radius corners is easy to keep clean and meets NSF Standard 7 for open food containers.
  • Environmentally friendly foamed-in-place CFC and HCFC-free polyurethane insulation enhances the structural strength of the cabinet and helps increase energy efficiency.
• Refrigeration System
  • Remote refrigeration models include expansion valve installed.
  • Condensate elimination is automatic and non-electric (except remotes).
  • Refrigeration system uses R134a refrigerant, which is CFC and HCFC-free for compliance with environmental safety concerns.
• Special Features
  • Keg storage is maximized in lieu of shelf storage when required.
• Electrical Connection
  • Units wired at factory and ready for connection to a 115/60/1 phase, 15 amp dedicated outlet. 8’ long cord and plug set included.
