Vulcan VPT15 Solid Door Mobile Pass-Thru Heated Holding Cabinet, 120 Volts

Name: Vulcan VPT15 Solid Door Mobile Pass-Thru Heated Holding Cabinet, 120 Volts
Brand: Vulcan
SKU: VPT15
Price: 9352.0 USD
Availability: InStock

MPN#: VPT15

1/3

Vulcan VPT15 Solid Door Mobile Pass-Thru Heated Holding Cabinet, 120 Volts

Free Freight?

Quick Ship

$9,352.00 /

Lowest Price Guarantee
Chat Now

Product Protection

Starting at

View all Vulcan Holding Cabinets

Vulcan VPT15 Specifications

Door Size	Full Height
Size	Full Height
Type	Holding Cabinets
Cabinet Type	Holding cabinets
Interior Construction	Shelves
Construction	Stainless Steel
Series	VPT Series
Insulated	Yes
Brand	Vulcan
Made in	USA
Certifications	cULus
Gauge	14 Gauge
Control Type	Thermostatic
Category	Heated Holding Cabinet, Mobile Pass-Thru
Door Type	Solid
Material	Stainless Steel
Sections	1
Style	Pass-Thru
Voltage	120 Volts
Width (in)	27
Height (in)	66.5
Depth (in)	34.5
Weight	297.00

Additional Information on Vulcan VPT15

sellsheet.pdf

brochure.pdf

parts-catalog.pdf

parts-list.pdf

owner-s-manual.pdf

vulcan-vpt15.specsheet.pdf

warranty-sheet.pdf

service-manual.pdf

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

Vulcan VPT15 Certifications

cULus

UL (Underwriters Laboratories) approval for the US and Canada

UL

UL has tested representative samples of this product and determined that the product meets specific, defined requirements.

UL EPH

Certifies that the goods conform to public health and environmental quality compatibility requirements.

UL EPH Classified

This product complies with UL EPH standards and meets ANSI/NSF requirements.

Vulcan VPT15 Description

Holding/Transport Cabinet, Pass-thru, Mobile, capacity (15) 18" x 26" x 1" or (30) 12" x 20" x 2-1/2" pans, forced air blower, side mounted push handles, recessed control panel, analog thermometer ambient to 190° F, includes (10) pair of universal tray slides adjustable 1-1/2" OC, 20 gauge stainless steel interior & exterior, 5" casters, cULus, UL EPH Classified

Standard Features:

Side mounted cord.
Field reversible doors.
Magnetic action door latch.
Recessed side mounted handles.
Dutch doors (VPT15 and VPT18).
Fully insulated with 11⁄2" in side walls and 2" in top.
Integrated stainless steel frame for maximum strength.
5" heavy duty casters (2 swivel with brakes and 2 rigid).
Blower motor for gentle and even temperature distribution.
ENERGY STAR® certified (all models except model VPT18).
Interior and the exterior are both constructed out of 20 gauge stainless steel.
Simple knob actuated electronic control for holding at temperatures up to 190°F.
Complete with cord and plug: NEMA 5-15 for 120 volts and NEMA 6-15 for 208-240 volts.
One year limited parts and labor warranty. After the first year, lifetime parts warranty on the heating elements.
Universal tray slides adjustable on 11⁄2" centers. VPT15 & VPT13 ship with 10 pairs of tray slides, VPT7 ships with 5 pairs and VPT18 ships with 15 pairs.
Pass-Thru Holding Capacity:
- 18" x 26" sheet pans.
- Other pan sizes on shelves.
- 12" x 20" pans, or a combination of both on 11⁄2" centers.

Options

208/240 volt
Humidity pan
Additional tray slides
Full perimeter bumper
Glass Dutch doors (VPT15 & VPT7 only)
Wire shelves to sit on tray slides (RACK-VCH)

Specifications

Vulcan Model No. VPT pass through holding cabinets. Blower motor for gentle and even temperature distribution. Complete with 5" heavy duty casters (2 swivel with brakes and 2 rigid). Simple knob actuated electronic control for holding at temperatures up to 190°F. Adjustable racking will hold 18" x 26" or 12" x 20" pans or a combination of both on 11⁄2" centers. Lip-load racking will hold 18" x 26" pans on 3" centers. Shelving will hold a variety of pan sizes. Cabinet interior and exterior are both constructed out of 20 gauge stainless steel. Recessed side-mounted handles, magnetic action door latch, and full insulation; 11⁄2" in side walls and 2" in top. Integrated stainless steel frame for maximum strength. Field reversible doors. Complete with side mounted cord and plug: NEMA 5-15 for 120 volts and NEMA 6-15 for 208-240 volts. One year limited parts and labor warranty. After the first year, lifetime parts warranty on the heating elements. ENERGY STAR® certified (all models except model VPT18).
