Vulcan VHFA9 Glass Door Mobile Heated Holding Cabinet, 120 Volts
SKU#: VHFA9
Calculate
Vulcan VHFA9 Specifications
| Control Type | Dial |
|---|---|
| Size | Half Height |
| Type | Holding Cabinets |
| Insulated | No |
| Interior Construction | Pan/Tray Slides |
| Brand | Vulcan |
| Made in | USA |
| Certifications | cULus |
| Category | Heated Mobile Cabinet, Single Section |
| Door Type | Clear |
| Style | Mobile |
| Voltage | 120 Volts |
| Width (in) | 25.25 |
| Height (in) | 45 |
| Depth (in) | 30.75 |
| Weight | 170.00 |
Additional Information on Vulcan VHFA9
parts-catalog.pdf
parts-list.pdf
sell-sheet.pdf
brochure.pdf
owner-s-manual.pdf
service-manual.pdf
vulcan-vhfa9.specsheet.pdf
warranty-sheet.pdf A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Vulcan VHFA9 Certifications
cULus
UL (Underwriters Laboratories) approval for the US and Canada
UL
UL has tested representative samples of this product and determined that the product meets specific, defined requirements.
UL EPH
Certifies that the goods conform to public health and environmental quality compatibility requirements.
Vulcan VHFA9 Description
Heated Cart, mobile, non-insulated, capacity (9) 18" x 26" x 1" sheet pans or (18) 12" x 20" x 2-1/2" steam table pans, fan & air tunnel, fixed tray slides 3" OC, glass door, stainless steel construction, 5" casters; 2 swivel, 2 rigid with locks, cULus, UL EPHStandard Features:
- Requires 120 volt, single phase power supply.
- Fan and air tunnel provide even heat distribution.
- Heavy duty 20 gauge polished stainless steel cabinet.
- Set of 5" casters, two swivel with brakes and two rigid.
- Two 600 watt metal sheathed heating elements,10 amps total draw.
- Furnished with top mounted 8 foot power cord with strain relief and NEMA 5-15 plug.
- Full size glass door with field reversible heavy duty hinges, door latch mechanism, and gaskets.
- One year limited parts and labor warranty. After the first year, lifetime parts warranty on the heating elements.
- Fixed interior pan supports are designed to accommodate pan covers for transporting, and are removable for easy cleaning.
- Nine level holding and transport cabinet accepts nine 18" x 26" pans or eighteen 12" x 20" pans, pans may be up to 2 3⁄4" tall.
- Top mounted, recessed control panel includes power “on” and heater “on” indicator lights, dial thermostat adjustable from ambient to 190°F, and temperature read-out dial.
- Top mounted control panel is easy to use and out of the way of brooms, mops, and feet when transporting. Control panel on top eliminates removing control panel for cleaning.
Nine level holding and transport cabinet, Vulcan Hart Model No. VHFA9. Heavy duty 20 gauge polished stainless steel cabinet. Four 5" casters, 2 swivel with brakes, 2 rigid. Glass door with heavy duty hinges, door latch mechanism, and gaskets. Interior pan supports are designed to accommodate pan covers for transporting, and are removable for easy cleaning. Accepts nine 18" x 26" pans or eighteen 12" x 20" x 2 3⁄4" pans. Top mounted, recessed control panel includes power “on” and heater “on” indicator lights, dial thermostat adjusts from ambient to 190°F, and temperature read-out dial. Two 600 watt metal sheathed heating elements, 10 amps total draw. One year limited parts and labor warranty. After the first year, lifetime parts warranty on the heating elements. Requires 120 volt, single phase power supply. Furnished with top mounted 8 foot power cord with strain relief and NEMA 5-15 plug. Classified by UL to NSF Std. #4.
