Vulcan V2B18B V Series Heavy Duty Range
MPN#: V2B18B
Calculate
- Please see specification sheet for installation clearance requirements
- Requires optional flue with back-splash or back-shelf.
- Additional required flue riser sold separately
Vulcan V2B18B Specifications
| BTU | 35,000 BTU |
|---|---|
| Number of Burners | 1 - 2 |
| Total BTU | 16000 - 130000 |
| Burner Type | 35,000 BTU open burners |
| Installation Type | Freestanding |
| Burner Style | Grates |
| Range Base Style | Storage Base |
| Brand | Vulcan |
| Made in | USA |
| Certifications | NSF |
| Legs | 6" adjustable legs |
| Exterior Finish | Stainless Steel |
| Base | Storage |
| BTU per Burner | 33000 |
| Category | Range 18" Heavy Duty, Gas |
| Heat | Gas |
| Number of Ovens | None |
| Range Configuration | Burners |
| Width (in) | 18 |
| Height (in) | 36 |
| Depth (in) | 36.75 |
| Weight | 225.00 |
Additional Information on Vulcan V2B18B
vulcan-v2b18bspecsheet.pdf
installation-operation.pdf
service-manual.pdf
parts-manual.pdf
sell-sheet.pdf
warranty-sheet.pdf A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Vulcan V2B18B Certifications
NSF
This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.
Vulcan V2B18B Description
V Series Heavy Duty Range, gas, 18", (2) 35,000 BTU open burners, cast iron grates, storage base with cabinet doors, stainless steel front, front top ledge, sides, base, burner box & stub back, 6" adjustable legs, 70,000 BTU, CSA, NSF
V Series Heavy Duty Range, gas, 18", (2) 35,000 BTU open burners, cast iron grates, storage base with cabinet doors, gas range, vulcan, food service equipment, commercial cooking equipment, stainless steel front, front top ledge, sides, base, burner box & stub back, 6" adjustable legs, 70,000 BTU, CSA, NSF, Commercial Gas Ranges
Standard Features:
- Heavy-duty cast grates
- 4" stainless steel stub riser
- Stainless steel cabinet base door
- One year limited parts and labor warranty
- Individual pilots and controls for each burner
- 33,000 BTU/hr. open top burners with lift off heads
- Universal rack guides, with one removable shelf (cabinet base)
- 1 1⁄4" diameter front gas manifold with 1 1⁄4" rear gas connection (capped)
- Stainless steel front, front top ledge, burner box, sides, base and stub back
- 6" adjustable stainless steel legs for cabinet base models (no legs for modular model)
- Cap and cover front manifold
- 3" high toe base for curb mounting
- 4" adjustable flanged feet for modular models
- Less legs for dolly mounting of cabinet base models
- Dolly frames
- Banking strip
- Set of 4 casters, 6" high (two locking)
- 10", 22", or 34" high back risers (no shelf)
- 22" single deck solid or flo-thru high shelf risers
- 34" double deck solid or flo-thru high shelf risers
- 6" adjustable flanged feet for cabinet base models
- Flexible gas hose with quick disconnect and restraining device
- Common condiment type, telescoping plate rail (starting at 24" length)
- 3⁄4", 1", or 11⁄4" gas pressure regulator (specify gas type - pack loose)
- Extra removable shelves for use with Universal rack guides (cabinet base)
