Vulcan 924RX 24'' Countertop Gas Griddle with Thermostatic Controls - 54,000 BTU
Calculate
Vulcan 924RX Specifications
| Plate Thickness | 1 Inch |
|---|---|
| Total BTU | 12000 - 55000 |
| BTU | 54,000 BTU |
| Installation Type | Countertop |
| Power Type | Natural Gas |
| Cooking Surface Material | Polished Steel |
| Construction | Stainless and Aluminized Steel |
| With Griddle | Yes |
| Brand | Vulcan |
| Griddle Plate Finish | Smooth Steel |
| Made in | USA |
| Certifications | NSF |
| Number of Burners | 4 |
| Burner Style | U-Shaped |
| Control Type | Thermostatic |
| Exterior Finish | Stainless Steel Front & Sides |
| Category | Griddle, Counter Unit, Gas |
| Controls | Thermostatic |
| Heat | Gas |
| Range Configuration | Griddle |
| Usage | Heavy Duty |
| Voltage | 120 Volts |
| Width (in) | 24 |
| Height (in) | 15.25 |
| Depth (in) | 31.5 |
| Weight | 285.00 |
Additional Information on Vulcan 924RX
corrections-sell-sheet.pdf
msa-control-system.pdf
parts-catalog.pdf
owner-s-manual-french.pdf
parts-list.pdf
service-manual.pdf
owner-s-manual.pdf
sell-sheet.pdf
vulcan-924rx.specsheet.pdf
warranty-sheet.pdf A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Vulcan 924RX Certifications
NSF
This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.
Vulcan 924RX Description
For commercial kitchens that need a gas-heated countertop griddle designed for heavy use, the 924RX Heavy Duty Gas Griddle from Vulcan is one of the best options available on the market. This griddle comes complete with thermostatic controls and a griddle plate that’s 24” wide. The 1” thick griddle plate is made from polished steel to make it easy to keep clean by preventing food from sticking. U-shaped burners heat the griddle plate efficiently.
This griddle features dual temperature control knobs that allow the cooking temperature of two zones from 200°F to 550°F. Heat is evenly applied to the griddle plate by spacing the two 27,000 BTU/hr U-shaped burners 12” apart. The pair of burners features a pilot safety valve for safety and the burners can be started with manual or electric ignition.
The stainless steel exterior sides, front, and front ledge make sure this unit will maintain its looks for years to come while keeping it easy to clean. For durability, the chassis is made from fully welded aluminized steel. This griddle has a 6 qt. capacity grease drawer to hold grease and debris from the cooktop. The grease drawer is made from stainless steel and is easy to remove from the front of the griddle making it simple and convenient to empty. Grease is easily moved into the drawer with a 3-½” wide grease trough.
The 11" cooking height of this griddle is easily kept level thanks to the included adjustable 4” legs.
In total, this griddle requires a gas input of 54,000 BTU/hr through its ¾” rear gas connection. A NEMA 5-15 plug is included to connect it to a 120v power source.
Standard Features:
- Bottom heat shields
- Dual (manual/electric) ignition.
- Manual shut-off valve for gas inlet.
- One year limited parts and labor warranty.
- Heavy duty chromed thermostat knob guards.
- 11" low profile cooking height on 4" adjustable legs.
- ¾" rear gas connection and gas pressure regulator.
- Fully welded stainless and aluminized steel chassis frame.
- 120V 50/60Hz 1 Amp single phase with NEMA 5-15 USA plug.
- Stainless steel front, sides and front top ledge with “Cool Bullnose” design.
- Large 6 quart stainless steel grease drawer (2 drawers on 60" and 72" models).
- One 27,000 BTU/hr. “U” shaped aluminized steel burner for every 12" of griddle width.
- One embedded snap action thermostat per burner with temperature adjust from 200°F to 550°F.
- 1" thick polished steel griddle plate with 12 gage, 4" stainless steel back and tapered side splashes.
- Spatula wide 3½" grease gutter and chute is fully welded for easier cleaning and to stop grease migration.
- One pilot safety valve for every two burners. Safety will completely shut off gas to pilot and burners if pilot extinguishes.
- 30" deep plate.
- Full or partially grooved griddle plate.
- Hexavalent chrome plated cooking surface.
- Stainless steel stand with marine edges and casters.
- Cutting board, condiment rail, plate rail and banking strip accessories.
Low profile heavy duty gas griddle. Stainless steel front, sides and front top ledge. Fully welded stainless and aluminized steel body frame. 11" low profile cooking height on 4" legs. 1" thick polished steel griddle plate with 12 gage, 4" stainless steel back and tapered side splashes. Grease chute is fully welded to stop grease migration. One 27,000 BTU/hr. “U” shaped aluminized steel burner and mechanical snap action thermostat for each 12" of griddle width. Chrome thermostat knob guards. Temperature adjusts from 200° to 550° F. One pilot safety for every two burners. Manual shut-off valve. 3 ½" wide stainless steel grease trough. 120V 50/60Hz 1 Amp single phase electric ignition circuit. Plug type is NEMA 5-15 USA. ¾" rear gas connection and gas pressure regulator. CSA design certified. NSF listed.
