Standard Product Features

• R-Series: Stainless Steel Exterior & Interior • A-Series: Stainless Steel Exterior/Anodized Aluminum Interior • INTELA-TRAUL® Microprocessor Control System • Ducted Fan Air Distribution System • Standard Operating Temperature Range 135 to 180°F • One-Time Start-Up Temperature Adjustment Feature • ON/OFF Switch Located On Control Face • Full or Half Length Stainless Steel Doors With Locks • Self-Closing Doors With Stay Open Feature At 120 Degrees • Guaranteed For Life Cam-Lift Hinges • Guaranteed For Life Horizontal Work Flow Door Handle(s) • Standard Door Hinging: 132W = Right, 232W = Left/Right, 332W = Left/Right/Right (other hingings available) • Automatically Activated Incandescent Lights • Stainless Steel Breaker Caps • Three Adjustable Wire Shelves Per Section, Supported On Pilasters (installed at the factory) • Special Heat Resistant Magnetic Snap-In Door Gaskets • Gasket Protecting Metal Door Liner • Stainless Steel One-Piece Louver Assembly • 9' Cord & Plug Attached (one section models only) • Set of Four (4) 6" High Adjustable Stainless Steel Legs • Three Year Parts And Labor Warranty

Standard interior arrangements include three (3) wire shelves per section, mounted on pilasters. Shelves are full-width, and do not have any large gaps between them requiring the use of "bridge" or "junior shelves." Recommended load limit per shelf should not exceed 225 lbs. Optional tray slides may be purchased in combination with, or in lieu of these. Both standard and optional interior arrangements are completely installed at the factory.

Options & Accessories

• Stainless Steel Finished Back With Rear Louvers • No. 1 Type Tray Slides To Accommodate either (1) 18" x 26" or (2) 14" x 18" Sheet Pans • No. 2 Type Tray Slides To Accommodate (1) 18" x 26" Pans • No. 3 Type Tray Slides To Accommodate (2) 12" x 20" Pans • No. 4 Type Tray Slides To Accommodate (1) 18" x 26" Pans (chrome rod type, equips 1/2 section) • Universal Type Tray Slides To Accommodate Either (1) 18" x 26" or (2) 14" x 18", or (2) 12" x 20" Pans • Additional Wire Shelves • Locking Hasps (padlocks supplied by others) • 115/60/1 Voltage (single section models only) • Export 220/50/1 Voltage • Stainless Steel Shelves In Lieu of Standard Wire • Kool Klad Exterior Laminate Decor • Set of Four (4) 4-5/8" or 6" High Casters In Lieu of Legs • 4-1/2" High Stainless Steel Base In Lieu of Legs • 6" High Stainless Steel Kickplate (for use with standard legs) • Prison/Correctional Facilities Options • Clear Glass Door(s) In Place Of One Or More Solid Door(s)

The easy to use, water resistant INTELA-TRAUL® microprocessor control system is supplied standard. Unit is NAFEM Data Protocol communication (NDP) ready. Optional hardware required to be NDP compliant. Third party software required for network connection. It includes a 3-Digit LED Display, ON/OFF Button, Fahrenheit or Celsius Temperature Scale Display Capability, One-Time Start-Up Temperature Adjustment Feature, and an RS485 data port. In addition it includes audio/visual alarms for: Hi/Lo Cabinet Temperature, Door Open and Power Supply Interruption.

A three year parts and labor warranty is provided standard.

A low watt density, serpentine style, heater is employed for the generation of electric heat. Low velocity air is forced across its large surface area to efficiently move heat radiating away from these through a down-air distribution duct, where it is then evenly distributed throughout the cabinet, assuring the proper holding environment for hot food product, without drying. A vent, located at the top of the cabinet, is included for positive humidity control.

Construction, Hardware and Insulation

Cabinet exterior front, one piece sides, louver assembly and doors are constructed of 20 gauge stainless steel with #4 finish. Cabinet interior and door liners are constructed of stainless steel (anodized aluminum in the A-Series). The exterior cabinet top, back and bottom are constructed of heavy gauge aluminized steel. A set of four (4) adjustable 6" high stainless steel legs are included. Doors are equipped with a gasket protecting metal door pan, removable plug cylinder locks and guaranteed for life cam-lift, gravity action, self-closing metal, glide hinges with stay open feature at 120 degrees. Hinges include a concealed switch to automatically activate the interior incandescent lighting. Guaranteed for life, work flow door handles are mounted horizontally over recess in door which limits protrusion from door face into aisleways. Doors have seamless, polished metal corners. Easily removable for cleaning, vinyl magnetic door gasket assures tight door seal. Both the cabinet and door(s) are insulated with an average of 2" thick high density, non-CFC, foamed in place polyurethane.

Traulsen AHF132W-FHG Spec-Line 1 Section 1 Clear Door Reach-In Heated Holding Cabinet - 24.8 cu. ft., 115/208-240 Volts

Name: Traulsen AHF132W-FHG Spec-Line 1 Section 1 Clear Door Reach-In Heated Holding Cabinet - 24.8 cu. ft., 115/208-240 Volts
Brand: Traulsen
SKU: AHF132W-FHG
Price: 12800.21 USD
Availability: InStock

SKU#: AHF132W-FHG

Traulsen AHF132W-FHG Spec-Line 1 Section 1 Clear Door Reach-In Heated Holding Cabinet - 24.8 cu. ft., 115/208-240 Volts

Free Freight?

Quick Ship

Energy Star ?

Products with Energy Star certification are designed to be more energy-efficient to maximize savings.

$12,800.21

Contact us for your price

Call 1 (800) 555-0666
Mon-Fri 9AM-8PM, Sun 12-6PM ET

Why don't we show the price for this item?

Product Protection

Starting at

Usually ships in 4-6 weeks

View all Traulsen Holding Cabinets

Traulsen AHF132W-FHG Specifications

Cabinet Capacity	24.8 cu. ft.
Door Size	Full
Size	Full Height
Cabinet Type	Heated Cabinets
Type	Holding Cabinets
Interior Construction	Shelves
Product Line	Spec Series
Series	Spec-Line
Construction	Stainless Steel and Aluminum
Insulated	Yes
Brand	Traulsen
Number of Doors	1
Energy Efficiency	Energy Star
Split Doors	No
Certifications	ETL
Controlled Humidity	Yes
Control Type	Microprocessor
Controls	Microprocessor
Capacity	21 - 27 cu. ft.
Door Type	Clear
Material	Aluminium
Sections	1
Style	Reach-In
Voltage	115/208-230 Volts
Wattage	1,500 Watts
Width (in)	29.88
Height (in)	83.25
Depth (in)	35
Weight	360

Additional Information on Traulsen AHF132W-FHG

warrantysheet.pdf

traulsensmartconnect.pdf

accessorykits.pdf

exteriorlaminates.pdf

trayracks.pdf

quick-start-guide.pdf

shipping-dimensions-product-weights.pdf

owner-s-manual.pdf

traulsen-ahf132w-fhg.specsheet.pdf

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

Traulsen AHF132W-FHG Certifications

ETL

The ETL Mark is proof of product compliance to North American safety standards.

ETL-Sanitation

This item meets the sanitation standards imposed by the ETL, a division of the Intertek Group.

Features
Standard Product Features:	• R-Series: Stainless Steel Exterior & Interior • A-Series: Stainless Steel Exterior/Anodized Aluminum Interior • INTELA-TRAUL® Microprocessor Control System • Ducted Fan Air Distribution System • Standard Operating Temperature Range 135 to 180°F • One-Time Start-Up Temperature Adjustment Feature • ON/OFF Switch Located On Control Face • Full or Half Length Stainless Steel Doors With Locks • Self-Closing Doors With Stay Open Feature At 120 Degrees • Guaranteed For Life Cam-Lift Hinges • Guaranteed For Life Horizontal Work Flow Door Handle(s) • Standard Door Hinging: 132W = Right, 232W = Left/Right, 332W = Left/Right/Right (other hingings available) • Automatically Activated Incandescent Lights • Stainless Steel Breaker Caps • Three Adjustable Wire Shelves Per Section, Supported On Pilasters (installed at the factory) • Special Heat Resistant Magnetic Snap-In Door Gaskets • Gasket Protecting Metal Door Liner • Stainless Steel One-Piece Louver Assembly • 9' Cord & Plug Attached (one section models only) • Set of Four (4) 6" High Adjustable Stainless Steel Legs • Three Year Parts And Labor Warranty
Interior:	Standard interior arrangements include three (3) wire shelves per section, mounted on pilasters. Shelves are full-width, and do not have any large gaps between them requiring the use of "bridge" or "junior shelves." Recommended load limit per shelf should not exceed 225 lbs. Optional tray slides may be purchased in combination with, or in lieu of these. Both standard and optional interior arrangements are completely installed at the factory.
Options & Accessories:	• Stainless Steel Finished Back With Rear Louvers • No. 1 Type Tray Slides To Accommodate either (1) 18" x 26" or (2) 14" x 18" Sheet Pans • No. 2 Type Tray Slides To Accommodate (1) 18" x 26" Pans • No. 3 Type Tray Slides To Accommodate (2) 12" x 20" Pans • No. 4 Type Tray Slides To Accommodate (1) 18" x 26" Pans (chrome rod type, equips 1/2 section) • Universal Type Tray Slides To Accommodate Either (1) 18" x 26" or (2) 14" x 18", or (2) 12" x 20" Pans • Additional Wire Shelves • Locking Hasps (padlocks supplied by others) • 115/60/1 Voltage (single section models only) • Export 220/50/1 Voltage • Stainless Steel Shelves In Lieu of Standard Wire • Kool Klad Exterior Laminate Decor • Set of Four (4) 4-5/8" or 6" High Casters In Lieu of Legs • 4-1/2" High Stainless Steel Base In Lieu of Legs • 6" High Stainless Steel Kickplate (for use with standard legs) • Prison/Correctional Facilities Options • Clear Glass Door(s) In Place Of One Or More Solid Door(s)
Controller:	The easy to use, water resistant INTELA-TRAUL® microprocessor control system is supplied standard. Unit is NAFEM Data Protocol communication (NDP) ready. Optional hardware required to be NDP compliant. Third party software required for network connection. It includes a 3-Digit LED Display, ON/OFF Button, Fahrenheit or Celsius Temperature Scale Display Capability, One-Time Start-Up Temperature Adjustment Feature, and an RS485 data port. In addition it includes audio/visual alarms for: Hi/Lo Cabinet Temperature, Door Open and Power Supply Interruption.
Warranties:	A three year parts and labor warranty is provided standard.
Heating System:	A low watt density, serpentine style, heater is employed for the generation of electric heat. Low velocity air is forced across its large surface area to efficiently move heat radiating away from these through a down-air distribution duct, where it is then evenly distributed throughout the cabinet, assuring the proper holding environment for hot food product, without drying. A vent, located at the top of the cabinet, is included for positive humidity control.
Construction, Hardware and Insulation:	Cabinet exterior front, one piece sides, louver assembly and doors are constructed of 20 gauge stainless steel with #4 finish. Cabinet interior and door liners are constructed of stainless steel (anodized aluminum in the A-Series). The exterior cabinet top, back and bottom are constructed of heavy gauge aluminized steel. A set of four (4) adjustable 6" high stainless steel legs are included. Doors are equipped with a gasket protecting metal door pan, removable plug cylinder locks and guaranteed for life cam-lift, gravity action, self-closing metal, glide hinges with stay open feature at 120 degrees. Hinges include a concealed switch to automatically activate the interior incandescent lighting. Guaranteed for life, work flow door handles are mounted horizontally over recess in door which limits protrusion from door face into aisleways. Doors have seamless, polished metal corners. Easily removable for cleaning, vinyl magnetic door gasket assures tight door seal. Both the cabinet and door(s) are insulated with an average of 2" thick high density, non-CFC, foamed in place polyurethane.
