Cleveland Range 24CGM200 Pressureless Convection Steamer

MPN#: 24CGM200
Free Freight?
Quick Ship
$37,848.30 /

Contact us for details

$32,441.40 /
or enjoy small payments $697.17/mo.
Lease Payment Calculate
Product Protection
Product Protection
Starting at
Reward Points
Reward Points
You will earn 37848
  • 3-Year Convection Steamer Door Warranty
  • Please see specification sheet for installation clearance requirements
  • Free Start-Up Program: Includes a performance check-out by Factory Authorized Servicer after installation and equipment demonstration by factory trained sales rep.
Additional Options and Accessories are Available.
Please call:
1 (800) 555-0666

Cleveland Range 24CGM200 Specifications

Pan Capacity3 Pans
Steam SourceBoiler
TypeConvection Steamers
BoilerYes
BrandCleveland Range
Number of Compartments2
Power TypeGas
BTU200,000 BTU
Interior FinishStainless Steel
ControlsManual
HeatGas
StyleFloor
Voltage120 Volts
Wattage1 Kilowatts
Width (in)23.62
Height (in)62
Depth (in)37
Weight610.00

Additional Information on Cleveland Range 24CGM200

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

Cleveland Range 24CGM200 Description

Pressureless Convection Steamer, gas, 24", (2) compartment, (3) 12 x 20 x 2-1/2" pans/per compartment capacity, solid state controls, 60-minute mechanical timer & manual (continuous steaming) bypass switch, left-hand hinged door, controls on right, instant steam standby mode, auto drain, steam shut-off switch, stainless steel construction, FSS stainless steel base frame, 220,000 BTU
Pressureless Convection Steamer, gas, 24", (2) compartment, (3) 12 x 20 x 2-1/2" pans/per compartment capacity, solid state controls, 60-minute mechanical timer & manual (continuous steaming) by-pass switch, left-hand hinged door, controls on right, instant steam standby mode, auto drain, steam shut-off switch, stainless steel construction, FSS stainless steel base frame, 200,000 BTU
Standard Features:
  • Stainless Steel Base Frame (FSS)
  • Modular Cabinet Base with Hinged Door.
  • Separate Main Power Switch for “On/Off”
  • All Controls are serviceable from the front.
  • Gas Pressure Regulator and Control Valve.
  • Standard Voltage for Control: 115 volts, 60 Hz, single phase.
  • Solid State Controls operate water level and safety functions.
  • Cooking Capacity for up to six 12˝ x 20˝ x 2 1⁄2˝ deep Cafeteria Pans.
  • Automatic Water Level Control System with Low Water Power Cut-off Circuit.
  • Left Hand Door Hinging: Compartment Doors hinged left, controls on the right.
  • NSF Certified 6˝ Stainless Steel Legs with adjustable flanged feet for a one inch level adjustment.
  • Durable 14 Gauge Stainless Steel Construction: For Compartment Door and Steam Cooking Cavity.
  • Automatic Generator Mineral Purging Cycle automatically cleans generator, reducing scale build up.
  • High Efficiency Gas Steam Generator, Electronic Spark Ignition and Automatic Water Fill on start up.
  • Pressureless cooking with forced convection steam, permitting doors to be opened while cooking continues.
  • Instant Steam Standby Mode: Holds generator at steaming temperature. Allows unit to start cooking instantly.
  • Automatic Generator Drain at shutdown: Contains a “Water Jet” Spray Rinse Cleaning Cycle to keep drain clear.
  • Steam generator equipped with High Limit Pressure Safety Switch, 15 psi Safety Valve, and Steam Generator Pressure Gauge.
  • Each compartment is equipped with a 60 minute mechanical timer, separate bypass switch for constant steaming and a cold water condenser for superior cooking results.
  • Exclusive “Cool to the Touch” Compartment Door Design: Free floating inner door with reversible door gasket provides an air tight seal. Stainless Steel Slam/Latch Door Latch mechanism provides greater reliability.
  • Secondary Low Water Cut-Off, factory installed (CALG) (Required for AZ. AR. CA. CO. CT. DE. FL. GA. HI. IL. IA. KS. MD. MA. MI. MN. MT. NE. NV. NM. NC. OK. OR. PR. RI. TN. UT. VA. WA. WV., Buffalo, NY, Wash. DC)
  • Exclusive Steam Cooking Distribution System: The exclusive Convection Jets produce a high velocity convection steam without fans. Curved Corner design in cooking compartment distributes heat evenly and is easy to keep clean. Creased top & bottom enhance drainage. Cold Water Condenser for each compartment maintains a dry steam. Fully insulated cooking compartment for thermal efficiency. Removable Stainless Steel Slide Racks for easy cleaning.
Options & Accessories:
  • Water Filters
  • Correctional Packages
  • Boiler Descaling Pump Kit (107142)
  • Quick Disconnect for gas line (QDC)
  • Cafeteria pans in depths of 1˝, 2 1⁄2˝, 4˝ and 6˝
  • Power Take Off Kit (GPTO), Kettle Interconnecting Kit (IMK-)
Cleveland’s “Best-in Class” product line offers the industry’s overall best “Standard Warranty Program” featuring:
  • Free Performance Start Up with Water Quality Check
    • Free Water Quality Check included with start up
  • 1-Year Door Gaskets and Adjustments included
    • 3, 5, 6 pan and 10 pan compartment steamers, non-part adjustments
  • 2-Year K-12 School Warranty included
    • 3-Year warranty included with purchase of Filter
  • 2-Year Warranty with Filter Purchase from Cleveland
    • Full 2-years parts and labor coverage
  • 5-Year Prorated for Pressure Boilers and Steam Generators
    • 100% covered for first 2 years with filter purchase
Specifications:
Two Compartments, CLEVELAND Convection Steamer, Model 24-CGM-200, Gas-fired Steam Generator, 200M BTU. Solid State Controls operate timing, water level and safety functions. Steam Generator with Automatic Water Fill on start-up, Automatic Blowdown with additional Manual Drain Valve and Electronic Spark Ignition. For each cooking compartment: 60 minute Mechanical Timer, Manual Operation Mode and Cold Water Condenser. Type 304 Stainless Steel cooking compartment.

Options for Cleveland Range 24CGM200

Correctional packages
K-12 warranty
Gas types
Filter options
What is included
  • Warranty: 1-year parts & labor warranty, standard
  • Performance start-up: Performance start-up included at customer request after equipment is installed (Free Water Quality Check included) (contact Cleveland Sales Representative for details)
  • Generator warranty: 5 year pro-rated parts warranty on boilers & steam generators
  • Door warranty: 3 year Convection Steamer Door Warranty, standard
  • Voltage: (VOS115) 120v/60/1-ph, 5.0 amps, 2-wire (DO NOT connect to GFI outlet)

Videos

NOTE! This is a general product line video and does not necessarily reflect the listed model.

Cleveland Range 24CGM200 Pressureless Convection Steamer

Cleveland Range 24CGM200 Accessories

Cleveland Range 24CGM200 Parts

All Cleveland Range 24CGM200 Parts

Cleveland Range 24CGM200 Reviews

There are no reviews yet for this product.

Questions and Answers

how long does it take to fill on start up
Per Cleveland a minimum flow rate of 35 psi will fill the tank in 6-7 minutes.
