Cleveland Range 24CGA10 Steamcraft Ultra 10 Convection Steamer

MPN#: 24CGA10
Cleveland Range 24CGA10 Steamcraft Ultra 10 Convection Steamer
Free Freight?
Quick Ship
$26,933.03 /

Contact us for details

$23,085.45 /
or enjoy small payments $496.11/mo.
Lease Payment Calculate
Product Protection
Product Protection
Starting at
Reward Points
Reward Points
You will earn 26933
  • 3-Year Convection Steamer Door Warranty
  • Please see specification sheet for installation clearance requirements
  • Free Start-Up Program: Includes a performance check-out by Factory Authorized Servicer after installation and equipment demonstration by factory trained sales rep.
Additional Options and Accessories are Available.
Please call:
1 (800) 555-0666

Cleveland Range 24CGA10 Specifications

Pan Capacity5 Pans
Steam SourceBoiler
TypeConvection Steamers
BoilerYes
BrandCleveland Range
Number of Compartments2
Power TypeGas
BTU125,000 BTU
Control TypeManual
Interior FinishStainless Steel
ControlsManual
HeatGas
StyleFloor
Voltage120 Volts
Wattage2 Kilowatts
Width (in)24
Height (in)65.5
Depth (in)33
Weight565.00

Additional Information on Cleveland Range 24CGA10

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

Cleveland Range 24CGA10 Description

Steamcraft® Ultra 10 Convection Steamer, pressureless, gas, 2 compartments, (5) 12 x 20 x 2 1/2 pans/compartment capacity, manual controls, easyTimer 90-minute timer with dial and LED digital readout in minutes and seconds, includes SureCook load compensating thermostat, manual cooking mode and descale indicator, left-hand hinged door, controls on right, steam shut-off switch, electronic spark ignition, 1 standard treated & tap water connection, stainless steel construction, 6" adjustable legs with flanged feet, 125,000 BTU
Steamcraft® Ultra 10 Convection Steamer, pressureless, gas, 2 compartments, (5) 12 x 20 x 2 1/2 pans/compartment capacity, manual controls, 60-minute mechanical timer & manual (continuous steaming) by-pass switch, left-hand hinged door, controls on right, steam shut-off switch, 1 standard treated & tap water connection, stainless steel construction, 6" adjustable legs with flanged feet, 125,000 BTU
Standard Features:
  • Left Hand Door Hinging: Compartment Doors hinged on the left, controls on the right.
  • Condensate Drip Trough: Provide under lower compartment door to collect condensate.
  • Easy Access Cleaning Port: Generator Cleaning Port located on the outside, top of the unit.
  • Cooking Capacity for up to ten 12˝ x 20˝ x 2 1⁄2˝ deep Cafeteria Pans, five each compartment.
  • NSF Certified 6˝ Stainless Steel Legs with adjustable flanged feet for a one inch level adjustment.
  • Durable 14 Gauge, 304 Stainless Steel Construction: For compartment door, cavity and steam generator.
  • Automatic Generator Drain: Contains a “Water Jet” Spray Rinse Drain Cleaning Cycle to keep drain clear.
  • Instant Steam Stand By Mode: Hold generator at a steaming temperature. Allows unit to start cooking instantly.
  • Two 60 Minute Electro-Mechanical Timers and Switches for manual operation: Audible signal for cooking time completion. (MCS)
  • Exclusive Automatic Probe for Water Level Control: Separate from the generator for easy access, contains a high velocity rinse cycle to eliminate mineral buildup.
  • Main Power On/Off Switch: Automatically fills generator with water, then ignites gas burners via a fully automatic Electronic Spark Ignition (pilot-less) to start generator.
  • Exclusive “Cool to the Touch” Two-Piece Compartment Door Design: Free floating inner door with reversible gasket provides an air tight seal. Stainless Steel Slam/Latch Door Latch mechanism for reliability.
  • Innovative PowerPak Gas Steam Generator: Unique 125,000 BTU, 80% efficient Vertical Atmospheric Generator Design, only uses 75M BTU when one compartment is used. Strong 14 Gauge Stainless Steel Construction. Large 7.5 gallon generator reservoir for high speed cooking production. Fully insulated rear mounted steam generator.
  • Exclusive Steam Cooking Distribution System: Exclusive Brass Steam Jets produce a high velocity convection steam without fans. Curved Corner design in cooking compartment distributes heat evenly, and is easy to keep clean. Creased top & bottom enhance  drainage. Cold Water Condenser for each compartment maintains a dry steam. Fully insulated cooking compartment for thermal efficiency. Removable Stainless Steel Slide Racks.
Options & Accessories:
  • 8˝ Stainless Steel Legs
  • Propane Gas option (PG)
  • Cafeteria Pans in depths of 1˝, 2 1⁄2˝ and 4˝
  • Compartment Door Steam Shut Off Switch (SCS)
  • Right hand Door Hinging, Controls on the Right (DHR)
  • Electronic Timer with Compensating Load Feature (ETC)
  • ON/OFF Steam Switch only for compartment controls (MC)
  • Dissolve ® liquid descaling kit. USDA and FDA approved (10617413)
Cleveland’s “Best-in Class” product line offers the industry’s overall best “Standard Warranty Program” featuring:
  • Free Performance Start Up with Water Quality Check
    • Free Water Quality Check included with start up
  • 1-Year Door Gaskets and Adjustments included
    • 3, 5, 6 pan and 10 pan compartment steamers, non-part adjustments
  • 2-Year K-12 School Warranty included
    • 3-Year warranty included with purchase of Filter
  • 2-Year Warranty with Filter Purchase from Cleveland
    • Full 2-years parts and labor coverage
  • 5-Year Prorated for Pressure Boilers and Steam Generators
    • 100% covered for first 2 years with filter purchase
Specifications:
CLEVELAND, SteamCraft Ultra 10, two compartments, Floor Model Steamer, Model 24-CGA-10, single, large capacity Gasfired Atmospheric Steam Generator, 125M BTU input. Remote Probe Type Water Level Controls. Steam Generator with Automatic Water Fill on start up, Automatic Generator Blowdown, Electronic Spark Ignition and Generator Stand-by for instant steam. Choice of Compartment Controls, Manual By Pass Operation Mode, Exclusive Cold Water Condenser design, Type 430 Stainless Steel exterior and cooking compartments.

Options for Cleveland Range 24CGA10

New Construction or Replacement
Correctional packages
K-12 warranty
Gas types
Installation of first and second units
Additional installation kits and services
Filter options
Extended warranty
Door hinging
What is included
  • Warranty: 1-year parts & labor warranty, standard
  • Performance start-up: Performance start-up included at customer request after equipment is installed (Free Water Quality Check included) (contact Cleveland Sales Representative for details)
  • Generator warranty: 5 year pro-rated parts warranty on boilers & steam generators
  • Door warranty: 3 year Convection Steamer Door Warranty, standard
  • Voltage: (VOS115) 120v/60/1-ph, 2.0 amps, 2-wire (DO NOT connect to GFI outlet)

Videos

NOTE! This is a general product line video and does not necessarily reflect the listed model.

Cleveland Range 24CGA10 Steamcraft Ultra 10 Convection Steamer

Cleveland Range 24CGA10 Accessories

Cleveland Range 24CGA10 Parts

All Cleveland Range 24CGA10 Parts

Cleveland Range 24CGA10 Reviews

There are no reviews yet for this product.

Questions and Answers

I need to change the door hinge on the standard (left-hinge) model to opposite (right-hinge) side. Is that an option or extra charge?
That is an option at time of order and has an extra charge as the controls also have to be moved.
