Vulcan V2BG18 Commercial Range, 36" W with 2 Burners (1) 18" Griddle and Modular Base - 100,000 BTU
MPN#: V2BG18
1/2
- Please see specification sheet for installation clearance requirements
- Requires optional flue with back-splash or back-shelf.
- Additional required flue riser sold separately
Vulcan V2BG18 Specifications
Number of Burners | 1 - 2 |
---|---|
Total BTU | 16000 - 130000 |
Quantity of Burners | 2 Burners |
Burner Type | 35,000 BTU open burners |
Burner Style | Grates |
Installation Type | Modular |
Range Base Style | Modular Base |
Brand | Vulcan |
BTU | 100,000 BTU |
Made in | USA |
Certifications | NSF |
Exterior Finish | Stainless Steel Front & Sides |
Base | Modular |
BTU per Burner | 33000 |
Category | Range, Gas, Heavy Duty, 36" |
Heat | Gas |
Number of Ovens | None |
Range Configuration | (1) 18" Griddle |
Width (in) | 36 |
Height (in) | 13.75 |
Depth (in) | 41.88 |
Weight | 332.00 |
Additional Information on Vulcan V2BG18
service-manual.pdf installation-operation.pdf sell-sheet.pdf parts-manual.pdf warranty-sheet.pdf vulcan-v2bg18.specsheet.pdf
A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Vulcan V2BG18 Certifications
NSF
This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.
Vulcan V2BG18 Description
V Series Heavy Duty Range, gas, 36", modular, (2) 35,000 BTU open burners, (1) 18" griddle, stainless steel front, front top ledge, sides, base, burner box & stub back, 4" flanged feet, 100,000 BTU, CSA Flame, CSA Star, NSF
V Series Heavy Duty Range, gas, 36", modular, (2) 35,000 BTU open burners, (1) 18" griddle, food service equipment, heavy duty range, vulcan, commercial cooking equipment, stainless steel front, front top ledge, sides, base, burner box & stub back, 4" flanged feet, 100,000 BTU, CSA Flame, CSA Star, NSF, Commercial Gas Ranges
Standard Features:
- Porcelain oven cavity
- Heavy-duty cast grates
- 4" stainless steel stub riser
- 3⁄4" ground steel griddle plate
- 30,000 BTU/hr. griddle burners
- 50,000 BTU/hr. standard oven burner
- 32,000 BTU/hr. convection oven burner
- One year limited parts and labor warranty
- Individual pilots and controls for each burner
- Stainless steel cabinet base doors for “B” models
- 33,000 BTU/hr. open top burners with lift off heads
- Universal rack guides, one removable shelf (cabinet base)
- 6" adjustable stainless steel legs for “S”, “C”, and “B” models
- 1 1⁄4" diameter front gas manifold with 1 1⁄4" rear gas connection (capped)
- Stainless steel front, front top ledge, burner box, sides, base and stub back
- Stainless steel oven cavity
- Cap and cover front manifold
- 3" high toe base for curb mounting
- Fan cooling package. (“C” models)
- 4" adjustable flanged feet for modular models
- 650°F oven thermostat and steel hearth. (“S” models)
- Less legs for dolly mounting for “S”, “C”, and “B” models
- Dolly frames
- Banking strip
- Set of 4 casters, 6" high (two locking)
- 10", 22", or 34" high back risers (no shelf)
- 22" single deck solid or flo-thru high shelf risers
- 34" double deck solid or flo-thru high shelf risers
- 6" adjustable flanged feet for “S”, “C”, and “B” models
- Flexible gas hose with quick disconnect & restraining device
- Common condiment type, telescoping plate rails (starting at 24" length)
- 3⁄4", 1", or 1 1⁄4" gas pressure regulator (specify gas type - pack loose)
- Extra removable shelves for use with Universal rack guides (for cabinet base)
