Vulcan V1FT18 V Series Heavy Duty Range
MPN#: V1FT18
- Please see specification sheet for installation clearance requirements
- Requires optional flue with back-splash or back-shelf.
- Additional required flue riser sold separately
Vulcan V1FT18 Specifications
BTU | 25,000 BTU |
---|---|
Number of Burners | 1 - 2 |
Total BTU | 16000 - 130000 |
Burner Style | French |
Installation Type | Modular |
Range Base Style | Modular Base |
Brand | Vulcan |
Made in | USA |
Certifications | NSF |
Exterior Finish | Stainless Steel |
Base | Modular |
Category | Range 18" Heavy Duty, Gas |
Heat | Gas |
Number of Ovens | None |
Range Configuration | French Top |
Width (in) | 18 |
Height (in) | 13.75 |
Depth (in) | 36.75 |
Weight | 220.00 |
Additional Information on Vulcan V1FT18
installation-operation.pdf parts-manual.pdf sell-sheet.pdf service-manual.pdf warranty-sheet.pdf vulcan-v1ft18.specsheet.pdf
A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Vulcan V1FT18 Certifications
NSF
This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.
Vulcan V1FT18 Description
V Series Heavy Duty Range, gas, 18", modular, French top, polished cast iron, individual pilots & controls, stainless steel front, front top ledge, sides, base, burner box & stub back, 4" flanged feet, 25,000 BTU, CSA, NSF
V Series Heavy Duty Range, gas, 18", modular, French top, polished cast iron, individual pilots & controls, stainless steel front, front top ledge, sides, base, burner box & stub back, 4" flanged feet, 25,000 BTU, CSA, NSF, Commercial Gas Ranges
Standard Features:
- 4" stainless steel stub riser
- Polished cast iron French Top
- Stainless steel cabinet base door
- 25,000 BTU/hr. burner (2 ring burner)
- One year limited parts and labor warranty
- Individual pilots and controls for each burner
- 1 1⁄4" diameter front gas manifold with 1 1⁄4" rear gas connection (capped)
- Stainless steel front, front top ledge, burner box, sides, base, and stub back
- 6" adjustable stainless steel legs for cabinet base units (no legs for modular model)
- Cap and cover front manifold
- 3" high toe base for curb mounting
- 4" adjustable flanged feet for modular models
- Less legs for dolly mounting of cabinet base models
- Universal rack guides, with one shelf (shelf is removable)
- Dolly frames
- Banking strip
- Set of 4 casters, 6" high (two locking)
- 10", 22", or 34" high back risers (no shelf)
- 22" single deck solid or flo-thru high shelf risers
- 34" double deck solid or flo-thru high shelf risers
- 6" adjustable flanged feet for cabinet base models
- Flexible gas hose with quick disconnect and restraining device
- Common condiment type, telescoping plate rails (starting at 24" length)
- 3⁄4", 1", or 1 1⁄4" gas pressure regulator (specify gas type - pack loose)
- Extra removable shelves for use with Universal rack guides (cabinet base)
