Vulcan 2TR85AF PowerFry3™ (2) 85-90 lb. Fryers Gas Floor Fryer with Solid State Controls and KleenScreen PLUS® Filtration System, 120 Volts - 180,000 BTU

SKU#: 2TR85AF
Made in USA
Free Freight?
Quick Ship
Energy Star Energy Star ?
Products with Energy Star certification are designed to be more energy-efficient to maximize savings.
$35,120.00
Lowest Price Guarantee
Chat Now
$27,175.24
or enjoy small payments $584.00/mo.
Lease Payment Calculate
Product Protection
Product Protection
Starting at
Reward Points
Reward Points
You will earn 35120
Additional Options and Accessories are Available.
Please call:
1 (800) 555-0666

Vulcan 2TR85AF Specifications

Filtration SystemKleenScreen PLUS® Filtration System
SeriesPowerFry3™
Control TypeSolid State
CabinetStainless Steel
BrandVulcan
Energy EfficiencyEnergy Star
Fry PotStainless Steel
Made inUSA
Battery2
CertificationsNSF
BasketTwin
Basket LiftsNo
BTU180,000 BTU
Exterior FinishStainless Steel Front & Sides
ControlsSolid State
Capacity(2) 85-90 lb. Fryers
Voltage120 Volts
Width (in)42
Height (in)47.25
Depth (in)34.38
Weight700.00

Vulcan 2TR85AF Certifications

NSF

NSF

This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.

Vulcan 2TR85AF Description

PowerFry3™ Fryer, gas, high efficiency, 42" W, (2) battery, 85-90 lbs. capacity per vat, solid state analog knob control with melt cycles, ThreePass™ heat transfer system, electronic ignition, KleenScreen PLUS® filtration system, twin baskets, stainless steel cabinet & fry tank, adjustable casters (2 swivel locking & 2 non-locking), 180,000 BTU, CSA, NSF, ENERGY STAR®

Operators that need a dual fryer setup with Commercial Deep Fryers that hold 85-90 lbs of oil are well served by the 2TR85AF PowerFry3™ Fryer from Vulcan. This gas-fired fryer system is extremely efficient and comes with filtration to keep operational costs as low as possible. These fryers are ENERGYSTAR® qualified and at the top of the list for the most efficient models available.

The efficiency of this fryer comes from the ThreePass™ heat transfer system. Unlike most fryers that use straight gas tubes to transfer heat to the frying oil, Vulcan has heat exchange tubes with two bends providing more surface area that heats oil without requiring more burners. Thanks to the revolutionary design, this fryer has 72% thermal efficiency and 60% cooking efficiency and while idle it only consumes 5,755 BTU/hr to maintain the cooking temperature. To prevent the oil from breaking down prematurely the SoftStart™ ignition system only uses 45,000 BTU/hr at startup to gently get oil to temperature.

Controlling the cooking temperature on this fryer is simple with a solid state analog knob behind the door which can set temperatures from 200° to 390°F. For ease of use, this fryer has an electronic ignition and selectable fat melt modes.

This fryer system’s KleenScreen PLUS® filtration system uses a stainless steel mesh to remove most particles. The filtration system is protected by a filter vessel made from 18 gauge stainless steel. If you need to filter out particles down to .5 microns, optional KleenScreen PLUS® filter envelopes can be ordered. Filtration is done quickly at a rate of 8 GPM thanks to a ⅓ HP pump motor.

Stainless steel construction of the cabinet and fry tank make sure cleaning and maintenance is as easy as possible. The fryer is easy to keep level thanks to the adjustable 6” casters which are handy for cleaning and maintenance tasks. Other equipment supplied with this fryer include twin fry baskets with plastic coated handles, a tank brush, and a clean-out rod.

A NEMA 5-15P cord and plug is included to connect the fryer to a 120-volt outlet and in total 90,000 BTU/hr of gas input is required.

Vulcan 2TR85AF PowerFry3™ (2) 85-90 lb. Fryers Gas Floor Fryer with Solid State Controls and KleenScreen PLUS® Filtration System, 120 Volts - 180,000 BTU

PowerFry3™ Fryer, gas, high efficiency, 42" W, (2) battery, 85-90 lb. capacity per vat, solid state analog knob control with melt cycles, ThreePass™ heat transfer system, electronic ignition, KleenScreen PLUS® filtration system, twin baskets, stainless steel cabinet and fry tank, adjustable casters (2 swivel locking & 2 non-locking), 180,000 BTU, CSA, NSF, ENERGY STAR®

Standard Features:
  • Hi-limit shut-off.
  • 90,000 BTU/hr. input.
  • Stainless steel cabinet.
  • Electronic matchless ignition.
  • Tank brush and clean-out rod.
  • 1 1⁄4" port ball type drain valve.
  • One year limited parts and labor warranty.
  • Set of four 6" adjustable (2 locking) casters.
  • Twin fry baskets with plastic coated handles.
  • Maintains idle temperature setting with only 5,575 BTU/hr. to save energy.
  • Stainless steel fry tank, 85 - 90 lb. capacity. Includes 10 year limited tank warranty.
  • Energy saving SoftStart™ ignition system extends oil life while requiring lower BTU’s.
  • Energy Efficient ThreePass™ heat transfer system yielding 60.0% cooking efficiency and 72% Thermal Efficiency. ENERGY STAR® certified.
Accessories
  • FRYMATE-VX21S add-on frymate.
  • 3⁄4" Flexible gas hose with quick disconnect.
  • Set of twin baskets - 8 3⁄4"w x 16 3⁄4"d x 6"h.
  • 10" high stainless steel removable splash guard.
  • Single large basket - 18 3⁄4"w x 17 1⁄4"d x 5 1⁄2"h.
  • Stainless steel tank cover - doubles as a work surface top.
  • Connecting Kit(s) - Connects two fryers together (brackets, grease strip and hardware included).
Options
  • Second year extended limited parts and labor warranty
Specifications
85 - 90 lbs. capacity free standing gas fryer, Vulcan-Hart Model No. (1TR85A) (1TR85D) (1TR85C). 90,000 BTU/hr. input. Stainless steel cabinet. Set of four 6" adjustable casters (2 locking). Stainless steel fry tank with ThreePass™ heat transfer system. Energy Star® certified. SoftStart™ ignition system using 45,000 BTU/hr. to extend oil life during start up. Idle rate of 5,575 BTU/hr. to maintain cooking temperature. 11⁄4" port ball type drain valve. Twin fry baskets with plastic coated handles. Solid state analog knob control, digital, or programmable computer control systems all standard with electronic matchless ignition. Tank brush and clean-out rod included. CSA design certified. NSF listed.
