Vulcan 2TR85AF PowerFry3™ (2) 85-90 lb. Fryers Gas Floor Fryer with Solid State Controls and KleenScreen PLUS® Filtration System, 120 Volts - 180,000 BTU
Chat Now
Vulcan 2TR85AF Specifications
Filtration System | KleenScreen PLUS® Filtration System |
---|---|
Series | PowerFry3™ |
Control Type | Solid State |
Cabinet | Stainless Steel |
Brand | Vulcan |
Energy Efficiency | Energy Star |
Fry Pot | Stainless Steel |
Made in | USA |
Battery | 2 |
Certifications | NSF |
Basket | Twin |
Basket Lifts | No |
BTU | 180,000 BTU |
Exterior Finish | Stainless Steel Front & Sides |
Controls | Solid State |
Capacity | (2) 85-90 lb. Fryers |
Voltage | 120 Volts |
Width (in) | 42 |
Height (in) | 47.25 |
Depth (in) | 34.38 |
Weight | 700.00 |
Additional Information on Vulcan 2TR85AF
A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Vulcan 2TR85AF Certifications
NSF
This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.
Vulcan 2TR85AF Description
Operators that need a dual fryer setup with Commercial Deep Fryers that hold 85-90 lbs of oil are well served by the 2TR85AF PowerFry3™ Fryer from Vulcan. This gas-fired fryer system is extremely efficient and comes with filtration to keep operational costs as low as possible. These fryers are ENERGYSTAR® qualified and at the top of the list for the most efficient models available.
The efficiency of this fryer comes from the ThreePass™ heat transfer system. Unlike most fryers that use straight gas tubes to transfer heat to the frying oil, Vulcan has heat exchange tubes with two bends providing more surface area that heats oil without requiring more burners. Thanks to the revolutionary design, this fryer has 72% thermal efficiency and 60% cooking efficiency and while idle it only consumes 5,755 BTU/hr to maintain the cooking temperature. To prevent the oil from breaking down prematurely the SoftStart™ ignition system only uses 45,000 BTU/hr at startup to gently get oil to temperature.
Controlling the cooking temperature on this fryer is simple with a solid state analog knob behind the door which can set temperatures from 200° to 390°F. For ease of use, this fryer has an electronic ignition and selectable fat melt modes.
This fryer system’s KleenScreen PLUS® filtration system uses a stainless steel mesh to remove most particles. The filtration system is protected by a filter vessel made from 18 gauge stainless steel. If you need to filter out particles down to .5 microns, optional KleenScreen PLUS® filter envelopes can be ordered. Filtration is done quickly at a rate of 8 GPM thanks to a ⅓ HP pump motor.
Stainless steel construction of the cabinet and fry tank make sure cleaning and maintenance is as easy as possible. The fryer is easy to keep level thanks to the adjustable 6” casters which are handy for cleaning and maintenance tasks. Other equipment supplied with this fryer include twin fry baskets with plastic coated handles, a tank brush, and a clean-out rod.
A NEMA 5-15P cord and plug is included to connect the fryer to a 120-volt outlet and in total 90,000 BTU/hr of gas input is required.
Standard Features:
- Hi-limit shut-off.
- 90,000 BTU/hr. input.
- Stainless steel cabinet.
- Electronic matchless ignition.
- Tank brush and clean-out rod.
- 1 1⁄4" port ball type drain valve.
- One year limited parts and labor warranty.
- Set of four 6" adjustable (2 locking) casters.
- Twin fry baskets with plastic coated handles.
- Maintains idle temperature setting with only 5,575 BTU/hr. to save energy.
- Stainless steel fry tank, 85 - 90 lb. capacity. Includes 10 year limited tank warranty.
- Energy saving SoftStart™ ignition system extends oil life while requiring lower BTU’s.
- Energy Efficient ThreePass™ heat transfer system yielding 60.0% cooking efficiency and 72% Thermal Efficiency. ENERGY STAR® certified.
- FRYMATE-VX21S add-on frymate.
- 3⁄4" Flexible gas hose with quick disconnect.
- Set of twin baskets - 8 3⁄4"w x 16 3⁄4"d x 6"h.
- 10" high stainless steel removable splash guard.
- Single large basket - 18 3⁄4"w x 17 1⁄4"d x 5 1⁄2"h.
- Stainless steel tank cover - doubles as a work surface top.
- Connecting Kit(s) - Connects two fryers together (brackets, grease strip and hardware included).
- Second year extended limited parts and labor warranty
