Traulsen AHT132NPUT-FHG 26.38'' 20.4 cu. ft. 1 Section Glass Door Pass-Thru Refrigerator
MPN#: AHT132NPUT-FHG
Free Freight?
Quick Ship
Energy Star ?Products with Energy Star certification are designed to be more energy-efficient to maximize savings.
$19,535.67 /
Contact us for your price
Call 1 (800) 555-0666
Mon-Fri 9AM-8PM, Sun 12-6PM ET
Mon-Fri 9AM-8PM, Sun 12-6PM ET
Why don't we show the price for this item?
Calculate
Product Protection
Starting at
- 2023 model, meets the newest EPA and DOE codes.
- Usually ships in 4-6 weeks
Traulsen AHT132NPUT-FHG Specifications
| Refrigerator Capacity | 20.4 cu. ft. |
|---|---|
| Amps | 8.3 Amps |
| Door Size | Full |
| Half Doors | No |
| Hinge Location | Right |
| Door Hinge | Right Hinged |
| Construction | Stainless Steel and Aluminum |
| Brand | Traulsen |
| Refrigerant Type | R-134A |
| Energy Efficiency | Energy Star |
| Split Doors | No |
| Made in | USA |
| Certifications | ETL |
| Number of Doors | 2 |
| Number of Shelves | 3 |
| Refrigeration System | Self-contained |
| Capacity | 11 - 30 cu. ft. |
| Compressor Location | Top Mounted |
| Door Type | Glass |
| Door Design | Swing |
| Material | Aluminium |
| Sections | 1 |
| Temperature Range | 34 - 38 Degrees F |
| Voltage | 115 Volts |
| Width (in) | 26.38 |
| Height (in) | 83.25 |
| Depth (in) | 37.93 |
| Weight | 440 |
Additional Information on Traulsen AHT132NPUT-FHG
warrantysheet.pdf
sellsheet.pdf
traulsensmartconnect.pdf
accessorykits.pdf
remotemodels.pdf
trayracks.pdf
exteriorlaminates.pdf
traulsen-aht132nput-fhgspecsheet.pdf
quick-start-guide.pdf
owner-s-manual.pdf
shipping-dimensions-product-weights.pdf A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Traulsen AHT132NPUT-FHG Certifications
ETL
The ETL Mark is proof of product compliance to North American safety standards.
ETL-Sanitation
This item meets the sanitation standards imposed by the ETL, a division of the Intertek Group.
Traulsen AHT132NPUT-FHG Description
Spec-Line Refrigerator, Pass-thru, one-section, self-contained refrigeration, variable speed compressor, stainless steel exterior, aluminum interior, standard depth, narrow full-height glass door on one side only with EZ-Clean Gaskets, (3) adjustable wire shelves per section, microprocessor controls, 6" adjustable stainless steel legs, R-290 Hydrocarbon refrigerant, 1/2 HP, cETLus, ETL-Sanitation, ENERGY STAR®
Spec-Line Refrigerator, Pass-thru, one-section, self-contained refrigeration, stainless steel exterior, aluminum interior, standard depth, narrow full-height glass door on one side only with Santoprene® EZ-Clean Gaskets, (3) adjustable wire shelves per section, microprocessor controls, 6" adjustable stainless steel legs, 1/3 HP, UL, UL-Sanitation
This pass-through refrigerator from Traulsen provides dual access to the interior so that the products can move from one station to another quickly and without the need for your staff to take multiple trips. Check out more top-quality pass-thru refrigerators and freezers here at CKitchen to complete your ultimate kitchen.
This pass-through refrigerator from Traulsen provides dual access to the interior so that the products can move from one station to another quickly and without the need for your staff to take multiple trips. Check out more top-quality pass-thru refrigerators and freezers here at CKitchen to complete your ultimate kitchen.
Standard Features:
The R & A Series “N-Width” refrigerator models are designed to offer maximum storage capacity within a slightly narrower left to right footprint. They are supplied standard with all the Traulsen top of the line features, such as balanced refrigeration systems, next-generation INTELA-TRAUL® controls, and stainless steel exteriors.
Construction, Hardware, and Insulation
- Cord & Plug Attached
- Stainless Steel Breaker Caps
- 5 Year Compressor Warranty
- Magnetic Snap-In Door Gaskets
- 1 Year Parts And Labor Warranty
- Guaranteed For Life Cam-Lift Hinges
- Three Chrome Plated Adjustable Shelves
- R-Series: Stainless Steel Exterior & Interior
- Automatically Activated Incandescent Lights
- Automatic, Non-Electric Condensate Evaporator
- INTELA-TRAUL® Microprocessor Control System
- Full or Half Length Stainless Steel Doors With Lock
- Set Of Four (4) 6" High Stainless Steel Adjustable Legs
- Guaranteed For Life Horizontal Work Flow Door Handle
- Self-Closing Door With Stay Open Feature At 120 Degrees
- A-Series: Stainless Steel Exterior/Anodized Aluminum Interior
- 3-Digit LED Display
- Internal Time Clock
- 72 Hour Data Storage
- Temperature Monitoring
- °F or °C Temperature Display Capability
- Visual & Audible Alarm Warnings For:
- Power Supply Interruption
- Hi/Lo Cabinet Temperature
- Door Open (cycles and time)
- Discharge Line Sensor Failure
- Evaporator Coil Sensor Failure
- Clogged Filter-Clean Condenser
- Stainless Steel Shelves
- Export 220/50/1 Voltage
- Decorative Kool Klad Decor
- Additional Chrome Plated Shelves
- Set of Four (4) Heavy Duty 6" High Casters
- Two Year Service/Labor Warranty Available
- Stainless Steel Finished Back With Rear Louvers
- Hinged Glass Doors (model number changes to FHG or HHG)
Construction, Hardware, and Insulation
- Cabinet exterior, including front, one-piece sides, louver assembly, and doors are constructed of heavy gauge stainless steel. Cabinet interior and door liners are constructed of stainless steel (anodized aluminum in A-Series). Exterior cabinet top and bottom are constructed of heavy gauge aluminized steel. A set of four (4) 6" high stainless steel adjustable legs is included. Doors are equipped with removable plug cylinder locks and guaranteed for life cam-lift, gravity action, self-closing metal, glide hinges with a stay-open feature at 120 degrees. Hinges include a switch to automatically activate the interior incandescent lighting. Guaranteed for life, work flow door handle is mounted horizontally over recess in door which limits protrusion from the door face into aisleways. Easily removable for cleaning, vinyl magnetic door gasket assures tight door seal. Anti condensate heaters are located behind each door opening. Cabinet and doors contain high density, non-CFC, foamed in place polyurethane insulation.
- A top-mounted, self-contained, balanced refrigeration system, using R-134a refrigerant is conveniently located behind the one-piece louver assembly. It features a plenum effect blower coil, large, high humidity evaporator coil located outside the food zone, top mounted non-electric condensate evaporator, and an automatic preset time activated electric defrost. Standard operating temperature is 34 to 38°F.
- The water-resistant INTELA-TRAUL® digital microprocessor control is provided. It includes an RS485 port for communications ability, in addition to features such as visual and audio alarms and 72-hour data storage capability.
- Standard interior arrangements include three (3) chrome-plated wire shelves. Recommended load limit per shelf should not exceed 225 lbs.
- The standard warranty includes a five-year compressor warranty and a one-year parts and labor warranty on all components and the cabinet. Additional warranties are available at extra cost. The INTELA-TRAUL® Control is warranted by a two-year parts and labor warranty
| Features | |
|---|---|
| Warranties: | The standard warranty includes a five year compressor warranty and a one year parts and labor warranty on all components and the cabinet. Additional warranties are available at extra cost. The INTELA-TRAUL® Control is warranted by a two year parts and labor warranty. |
| Construction, Hardware and Insulation: | Cabinet exterior, including front, one piece sides, louver assembly and doors are constructed of heavy gauge stainless steel. Cabinet interior and door liners are constructed of stainless steel (anodized aluminum in A-Series). Exterior cabinet top and bottom are constructed of heavy gauge aluminized steel. A set of four (4) 6" high stainless steel adjustable legs is included. Doors are equipped with removable plug cylinder locks and guaranteed for life cam-lift, gravity action, self-closing metal, glide hinges with stay open feature at 120 degrees. Hinges include a switch to automatically activate the interior incandescent lighting. Guaranteed for life, work flow door handle is mounted horizontally over recess in door which limits protrusion from door face into aisleways. Easily removable for cleaning, vinyl magnetic door gasket assures tight door seal. Anti condensate heaters are located behind each door opening. Cabinet and doors contain high density, non-CFC, foamed in place polyurethane insulation |
| Standard Features: | • R-Series: Stainless Steel Exterior & Interior • A-Series: Stainless Steel Exterior/Anodized Aluminum Interior • INTELA-TRAUL® Microprocessor Control System • Full or Half Length Stainless Steel Doors With Lock • Self-Closing Door With Stay Open Feature At 120 Degrees • Guaranteed For Life Cam-Lift Hinges • Guaranteed For Life Horizontal Work Flow Door Handle • Automatically Activated Incandescent Lights • Stainless Steel Breaker Caps • Three Chrome Plated Adjustable Shelves • Automatic, Non-Electric Condensate Evaporator • Magnetic Snap-In Door Gaskets • Set Of Four (4) 6" High Stainless Steel Adjustable Legs • Cord & Plug Attached • 1 Year Parts And Labor Warranty • 5 Year Compressor Warranty |
| Interior: | Standard interior arrangements include three (3) chrome plated wire shelves. Recommended load limit per shelf should not exceed 225 lbs. |
| Controller: | The water resistant INTELA-TRAUL® digital microprocessor control is provided. It includes an RS485 port for communications ability, in addition to features such as visual and audio alarms and 72 hour data storage capability. |
| Refrigeration System: | A top mounted, self-contained, balanced refrigeration system, using R-134a refrigerant is conveniently located behind the one piece louver assembly. It features a plenum effect blower coil, large, high humidity evaporator coil located outside the food zone, top mounted non-electric condensate evaporator, and an automatic preset time activated electric defrost. Standard operating temperature is 34 to 38°F. |
| KEY FEATURES: | • 3-Digit LED Display • Temperature Monitoring • Internal Time Clock • 72 Hour Data Storage • °F or °C Temperature Display Capability • Visual & Audible Alarm Warnings For: (1) Hi/Lo Cabinet Temperature, (2) Evaporator Coil Sensor Failure, (3) Clogged Filter-Clean Condenser, (4) Discharge Line Sensor Failure, (5) Power Supply Interruption, (6) Door Open (cycles and time) |
| Options & Accessories: | • Stainless Steel Finished Back With Rear Louvers • Export 220/50/1 Voltage • Set of Four (4) Heavy Duty 6" High Casters • Stainless Steel Shelves • Additional Chrome Plated Shelves • Decorative Kool Klad Decor • Hinged Glass Doors (model number changes to FHG or HHG) • Two Year Service/Labor Warranty Available |
