Garland US Range M8S Master Series Heavy Duty Range

MPN#: M8S
Garland US Range M8S Master Series Heavy Duty Range
Free Freight?
Quick Ship
$4,107.00 /

Contact us for details

$3,360.00 /
or enjoy small payments $72.21/mo.
Lease Payment Calculate
Product Protection
Product Protection
Starting at
Reward Points
Reward Points
You will earn 4107
  • Please see specification sheet for installation clearance requirements
  • Additional required flue riser sold separately

Garland US Range M8S Specifications

BTU 33,000 BTU
Number of Burners1 - 2
Total BTU16000 - 130000
Installation TypeFreestanding
Burner StyleH-Shaped
Range Base StyleStorage Base
BrandGarland/US Range
CertificationsNSF
Control TypeThermostatic
Exterior FinishStainless Steel Front & Sides
BaseStorage
ControlsThermostatic
Gas TypeLP
HeatGas
Number of OvensNone
Range ConfigurationGriddle
Width (in)17
Height (in)36.38
Depth (in)38
Weight260.00

Additional Information on Garland US Range M8S

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

Garland US Range M8S Certifications

NSF

NSF

This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.

Garland US Range M8S Description

Master Series Heavy Duty Range, gas, 17", Add-A-Unit, griddle, 1" thick steel plate, thermostatic controls, storage base, stainless steel front, sides, splashguards & door, 6" adjustable legs, 33,000 BTU, CSA Flame, CSA Star, NSF (Garland)
This 17" heavy-duty commercial gas range fits a griddle and storage cabinet in a single unit. The griddle plate is 1" thick so it can retain heat for longer periods and cut down recovery time in between batches. It has a 33,000 BTU H-shaped burner to spread the heat evenly. To keep your workspace clean and safe, there is a stainless steel splash guard that catches splashes and spills. The cabinet base is concealed behind a stainless steel door and makes sure the supplies you need for daily cooking are within reach at all times.

The front and sides of this commercial range are made of stainless steel so they stay tough even with daily heavy use. The entire unit is mounted on 6" chrome steel legs that can be adjusted to various working heights.

This heavy-duty range comes with CSA Flame, CSA Star, and NSF certifications.

Browse other high-quality restaurant and heavy-duty ranges and commercial cooking equipment here at CKitchen to complete your setup!
Master Series Heavy Duty Range, gas, 17", Add-A-Unit, griddle, 1" thick steel plate, thermostatic controls, storage base, stainless steel front, sides, splashguards & door, 6" adjustable legs, 33,000 BTU, CSA Flame, CSA Star, NSF (Garland)
Standard Features:
  • Stainless steel door
  • Stainless steel front and sides
  • Storage base interior of aluminized steel
  • 6" (152mm) chrome steel adjustable legs
  • Removable stainless steel grease drawer
  • Aluminized steel under all cooking, surfaces
  • Clip on stainless steel backsplash for griddle plate
  • Thermostat control with embedded capillary line sensors
  • 2-5/16" (59mm) high welded stainless steel splash guards, sides back
  • 1" (25mm) thick Steel griddle plate with 33,000 BTU, (9.67 kW), "H" type burner
Optional Features:
  • Dais base (S model)
  • Modular stand, (T model)
  • Stainless steel main back
  • Gas regulator 3/4" or 1-1/4"
  • End caps and cover (NC, specify)
  • Rear gas connection, 3/4" or 1" NPT
  • Celsius dial for griddle thermostat (NC)
  • Gas shut off valve; 3/4", 1" or 1- 1/4" NPT
  • 6" (152mm) stainless steel adjustable legs
  • Fully grooved griddle, (or grooved section)
  • Stainless steel tubular high shelf, single or double deck
  • Set of (4) Polyurethane non‑marking swivel casters w/front brakes
  • Stainless steel backguard: 10" (354mm), 17" (432mm) or 33" (838mm) H
  • Stainless steel common front rail up to 102" (2591mm) wide (two or more units in a battery)
  • Gas flex hose & quick disconnect (3/4", 1" or 1-1/4" NPT x 5') w/restraining device, please specify
Specifications:
The 1" (25mm) thick steel griddle plate is 17" wide x 24-3/4" deep, (433mm x 629mm) and bordered by side and rear continuous-welded stainless steel splash guards. The 33,000 BTU, (9.67 kW), "H" burner controlled by a thermostat provides uniform heat. Heavy gauge aluminized steel radiation baffle requires no fire brick, heats evenly, increases thermal efficiency. Natural or propane gas, Model M8T. NOTE: Attachments supplied with casters must be installed with an approved restraining device.

Options for Garland US Range M8S

Range finishes
Common front rail
Gas connection
Security options
Extended warranty
Griddle options
Gas type
Mounting options
What is included
  • Standard parts/labor warranty: Two year limited parts and labor warranty, covers products purchased and installed in the USA only, standard
  • NOTE: Note: All Master Series Ranges, storage, modular, fryers, attachment & under-fired char broilers require a high shelf or back guard attachment
