Frymaster 11814G 51 - 90 lb. Gas Floor Model Full Pot Fryer with SMART4U® Lane Controls - 119,000 BTU

SKU#: 11814G
Made in USA
Free Freight?
Quick Ship
Energy Star Energy Star ?
Products with Energy Star certification are designed to be more energy-efficient to maximize savings.
$10,405.40

Contact us for details!!!

$10,405.40
or enjoy small payments $223.61/mo.
Lease Payment Calculate
Product Protection
Product Protection
Starting at
Reward Points
Reward Points
You will earn 10405

Frymaster 11814G Specifications

Total BTU119,000 BTU
BTU119,000 BTU
Control TypeElectonic
SeriesEnerlogic®
Installation TypeFloor Model
ConstructionStainless Steel
Burner StyleTube
BrandFrymaster
Energy EfficiencyEnergy Star
Made inUSA
CertificationsNSF
Power TypeGas
ControlsSMART4UВ® Lane
Capacity51 - 90 lb.
HeatNatural or Propane Gas
Width (in)20
Height (in)47.75
Depth (in)33.13
Weight255.00

Frymaster 11814G Certifications

NSF

NSF

This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.

Frymaster 11814G Description

Frymaster® Fryer, gas, floor model, 63 lb. capacity, full frypot, oil conserving, tube-type design, 18" x 14" cooking area, electronic ignition, includes: rack-type basket supports, basket hangers, (3) twin baskets, stainless steel frypot, door & cabinet sides, 119,000 BTU, CSA, NSF, ENERGY STAR®, Enerlogic®

The 11814G tube-type floor model gas fryer by Frymaster has a single 63-lb frypot with a spacious 18" x 14" x 3.75" cooking area that can accommodate three baskets of food! This means you cook more for less oil and lower energy in a smaller footprint! With 119,000 BTU per frypot, this commercial gas fryer will be an asset to businesses with high frying demands. Compared to standard 50-lb Commercial Deep Fryers, this ENERGY STAR unit will save you as much as 12-20% on oil, 50% on energy, and 11-15% on space.

Excellent heat transfer

This unit features a Thermo-Tube heat transfer system that has larger 6" diameter tubes with durable high-heat stainless steel alloy flow baffles for enhanced heat-to-oil transfer, boosting your energy savings and maximize the life of the oil. The stainless steel construction on the frypot, door, cabinet sides, and over-the-flue basket hangers makes for a rugged unit that will hold up well to heavy applications.

Intelligent controls

The 11814G gas fryer is equipped with a SMART4U® Lane controller complete with programmable cook buttons that give you total control of your frying operations. The RTD, 1° compensating temperature probe provides pinpoint temperature readings for consistent cooking.

Easy maintenance

The large cold zone collects the sediment to keep the cooking area and the oil pristine so you can always make sure that the fried food that comes out of the fryer is high-quality. The bottom of the frypots is slanted toward the front and use a large drain line with a safety switch to make filtration and maintenance much quicker, easier, and safer.

The 11814G gas fryer ships with rack-type basket supports and basket hangers. It is CSA and NSF approved so you can use this commercial fryer with confidence! Get more top-of-the-line commercial deep fryers and cooking equipment here at CKitchen!

Standard Features:
  • Drain safety switch
  • Three twin baskets per frypot
  • Stainless steel frypot, door and cabinet sides
  • Robust, RTD, 1° compensating temperature probe
  • Sturdy stainless steel over-the-flue basket hangers
  • 21814GF, 31814GF, 41814GF come standard with filtration and casters
  • Wide cold zone traps sediment away from cooking area, safeguarding oil
  • Thermo-Tube heat-transfer system efficiently transfers energy into the oil, saving energy and extending oil life
  • 119,000 Btu/hr (29,975 kcal/hr.) (34.9 kw/hr.) input per frypot meets high production demands of a varied menu
  • 18” x 14” x 3-3/4” frying area per frypot uses 63 lbs of oil and cooks three twin baskets of food at the same time
  • SMART4U® Lane controller has programmable cook buttons and features that make it easy to produce consistent, great-tasting food.
11814/HD50G/11814 Has Standard Features of the Batteries Above Plus:
  • Two additional twin baskets
  • Built-in filter for 11814G model
  • Digital, CM3.5, and SMART4U® 3000 controllers
  • Spreader cabinet(s) - must fit within 4-cabinet fryer battery
  • Bulk oil (dispose and fresh fill) on batteries with built-in filtration
  • The HD50 frypot has a 2-Lane controller with all the features of the 3-Lane controller except that it  manages the cooking of 2-twin baskets instead of three
  • A high efficient HD50G frypot that exceeds ENERGY STAR® guidelines, with a 50-lb oil capacity, 100,000 Btu/hr. (25,189 kcal/hr.) (29.3 kw/hr.), and a 14” x 14” x 3-1/2”(35.6 x 35.6 x 8.9 cm) cooking area
  • External oil discharge (dispose only) available on built-in filter batteries of two or more frypots. Must specify front or rear connection. Front connection comes with 5’ washdown hose (precludes bulk rear oil discharge)
Options & Accessories
  • Fish plate
  • Full basket
  • Dual basket
  • Quad basket
  • Splash shield
  • Frypot covers
  • Sediment tray
  • Chicken basket
  • Foam deck basket banger
  • Casters (included on filter models)
  • Quick disconnect with gas line and adapter
    • 1” x 48”
    • 1” x 36”
    • 3/4” x 36” (11814 only)
    • 3/4” x 48” (11814 only)

Options for Frymaster 11814G

Installation/Disposal
Start-up program
Gas types
Controls
Standard warranty
Mounting options
What is included
  • Manufacturer's note: Note: Prices listed are for within the USA only. Please contact the factory for pricing if quoting outside of the USA
  • Curb note: NOTE: Gas fryers CANNOT be curb mounted
