Champion 66 PRO-HR Pro Series Conveyor Dishwasher 66"W

MPN#: 66 PRO-HR

Product photo not available at the moment

OPTIONS
REVIEWS
Q & A
RECOMMENDED ITEMS

Free Freight?

Quick Ship

$54,132.40 /

Sign-In here for more information

$51,155.12 /

or enjoy small payments $1,099.32/mo.

Calculate

Product Protection

Starting at

Reward Points

You will earn 54132

$$$ View Champion Promos

View all Champion Conveyor Type Dishwashers

Champion 66 PRO-HR Specifications

Made in	USA
Certifications	cULus

Champion 66 PRO-HR Certifications

cULus

UL (Underwriters Laboratories) approval for the US and Canada

NSF

This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.

Champion 66 PRO-HR Description

Pro Series Conveyor Dishwasher, 66"W, (44" single tank + 22" prewash), Proportional Rinse, Progressive anti-jam drive system, top mounted Prodigy series HMI user interface, Proactive maintenance software,100 gallons per hour with energy sentinel (idle pump shut-off), (209) racks per hour, single-piece hood design, single-piece stainless steel upper & lower wash arms manifolds, internal removable scrap basket, dual-piece scrap screens, 20” standard vertical clearance which accommodate 18” x 26” sheet pans, full 180° opening leak proof insulated hinged access doors, automatic tank fill, door safety switches, leak-proof ball valve drains, lower front & side enclosure panels, stainless steel heavy gauge construction including base & legs, electric tank heat with heat recovery, heat recovery cabinet to come standard with single vent cowl, internal booster heater included, 2 HP prewash and wash pumps, single point machine & booster connection, vent fan control, stainless steel rear manifolds, NSF Pot & Pan mode, cULus, Made in USA

Options for Champion 66 PRO-HR

Hood options

20" High hood vertical clearance for sheet pans (standard) 24" Vertical clearance through machine +$1,894.79

Feet option

Flanged feet +$180.39

Splash shield

Splash shield (set) +$421.14

Automatic loading/unloading options

Cantilever side loader, 24", no hood +$6,343.00 Cantilever side loader, 30", no hood +$9,818.51

Detergent & Rinse option

Detergent and Rise Pumps +$1,316.62

Tank heat options

Electric tank heat with heat recovery, standard Stainless steel steam coil tank heat with heat recovery +$3,211.41

Machine voltage

208v/60/1-ph 208v/60/3-ph 240v/60/1-ph 240v/60/3-ph 480v/60/3-ph Export voltage +$1,112.86

Additional racks

Flat Bottom Dishrack, 20" x 20", additional +$96.69 Peg Dishrack, 20" x 20", additional +$96.69

Connectivity

Direct Link: Features remote access service & performance diagnostics by the Champion factory technical support team +$2,005.10 Direct Link Plus: Features remote access service & performance diagnostics by the Champion factory technical support team. Includes cloud storage & online user access. Temperature & performance data is stored via the cloud and is accessed through an online portal. Initial term for this upgrade is three years +$2,920.05

Clean dish roller table options

Roller Conveyor Table, 64", stationary, unload end, includes: whisker style table limit switch +$5,376.79 Roller Conveyor Table, 84", stationary, unload end, includes: whisker style table limit switch +$7,021.10 Roller Conveyor Table, 144", stationary, unload end, includes: whisker style table limit switch +$12,461.48

Water Conditioner

Champion ION Scale Prevention System (unmounted) (1-HW, 1-CW for HR or VHR Models) +$2,592.36

Direction of operation

Left-to-right operation Right-to-left operation

Back panel

Stainless steel rear enclosure panels, priced per foot of machine (consult factory for price)

Limit switch options (must choose one)

Table Limit Switch (Whisker Style) Table limit switch, includes: 12 ft. pre-wired cord standard (unmounted) (recommended on all conveyor models) +$487.97 Table Limit Switch (Buttom Style) Table limit switch, includes: 12 ft. pre-wired cord standard (unmounted) (recommended on all conveyor models) +$487.97

Ventilation options

Stainless steel vent cowl with 7" stack & locking damper (load end) +$845.52 Extended stainless steel vent cowl with 7" stack & locking damper (load end) +$918.84

Water related options

Water pressure regulating valve (unmounted) +$310.82 Drain Water Tempering Kit (Unmounted) +$1,363.34 Shock Arrestor (unmounted) +$123.94

Correctional package

Low to Medium Security Package: Includes stainless steel locking grid over control cabinet, tamper proof screws, hinged lid on PW basket, welded curtain hooks, lockable doors (Locks by others), mesh cover on pressure gauge (consult factory for price) High Security Package: Includes stainless steel locking grid over control cabinet, tamper proof screws, hinged lid on PW basket, welded curtain hooks, lockable doors (Locks by others), mesh cover on pressure gauge, stainless steel grid underneath, metallic lined flexible conduit (consult factory for price)

Extended warranty

2nd year limited parts & labor warranty +$2,206.26 End of Warranty Tune-Up: Initial, then follow up resolution visit, during normal 8-5 business hours, at the end of the normal warranty period. Thorough diagnosis of all machine components, with proactive replacement of specific parts, including wearable parts (consult factory for wear parts). Full parts & labor coverage. If customer is beyond 60 miles from Champion authorized service agent, consult factory. +$3,861.47

What is included

Note: Complimentary factory authorized performance test included, upon equipment start-up. Consult local Champion sales representative for coordination of the start-up. If customer is beyond 60 miles from Champion authorized service agent, consult factory.
Standard warranty: 1 year parts & labor warranty, standard
Water Treatment Options:: Note: For water of 3-grains of hardness or more, Champion recommends adding a water treatment device.
