Champion 44 PRO Pro Series

Pro Series, 44”W rack conveyor dishwasher, Proportional Rinse, Progressive anti-jam drive system, top mounted Prodigy series HMI user interface, Proactive maintenance software,100 gallons per hour with energy sentinel (idle pump shut-off), (209) racks per hour, single-piece hood design, single-piece stainless steel upper & lower wash arms manifolds, internal removable scrap basket, dual-piece scrap screens, 20” standard vertical clearance which accommodate 18” x 26” sheet pans, full 180° opening leak proof insulated hinged access doors, automatic tank fill, door safety switches, leak-proof ball valve drains, lower front & side enclosure panels, stainless steel heavy gauge construction including base & legs, electric tank heat, 2 HP wash pump, single point machine & booster connection, vent fan control, stainless steel rear manifolds, includes: (1) 20" x 20" peg rack & (1) 20" x 20" flat rack, NSF Pot & Pan mode, cULus, ENERGY STAR®, Made in USA

If you need to replace or upgrade your rack Conveyor Type Dishwasher the 44 PRO Pro Series from Champion is an excellent option.  This washer unit is NSF rated to handle 209 racks per hour while using 100 gallons of water per hour.

Monitoring the performance and configuring settings is made simple with the Prodigy series HMI display. The user-friendly touch controls provide visual guidance for cleaning and operation.  Proactive maintenance tasks and self-diagnostics allow for quick recognition of issues and can recommend the necessary repairs.

With 20” of vertical clearance 18” x 26” sheet pans fit with no issue while automatic rack alignment positions racks into the optimal wash zone. Racks are moved by the perpetual rack advance system and an intuitive jam alert protects the drive from damage in case something goes wrong.

The heavy-gauge stainless steel construction makes sure this washer will last for many years in operation without issue. The unit features a single-piece hood design and stainless steel upper and lower wash arm manifolds. The leak-proof doors can fully open to 180° and feature insulation. Door safety switches are included to keep workers safe.

Consistent water pressure is provided by a 2 HP pump motor with a stainless steel impeller that provides 100 gallons per minute and features the energy sentinel system to limit energy costs.

The wash tank automatically fills and is heated to maintain the water temperature between wash cycles while an electric booster makes sure rinse water is always sanitary. The proportional rinse system delivers unmatched coverage thanks to digital pattern cloning for efficient use of water.

• Vent fan control
• Made in America
• 209 racks per hour
• Single-piece hood design
• Factory Authorized Start-up
• ENERGY STAR® Qualified
• Automatic drain valve Exclusive!
• Enclosure panels (front and sides)
• 2 HP pump motor, with stainless steel impeller
• 100 GPH with energy sentinel (idle pump shut-off)
• Full 180° opening leak proof insulated hinged access doors
• Single-piece stainless steel upper and lower wash arm manifolds
• Single point electrical connection, machine and built-in booster heater
• Stainless steel heavy gauge construction including base, legs and feet
• Perpetual rack advance system, with intuitive jam alert, and drive protection
• Programmable machine dwell with automatic rack alignment into the optimal wash zone
• 20" standard vertical clearance which accommodates 18" x 26" sheet pans pump motor, with stainless steel impeller
• Proportional rinse, delivering unmatched total ware coverage, utilizing digital pattern cloning, stainless steel nozzles
• Proactive maintenance interface, self-diagnostics, problem recognition, with repair recommendation, from HMI touch screen
• Prodigy series HMI display, intuitive condition alerts, with user friendly cleaning and operation visual guidance, multi-lingual, touch control

• Booster Heaters (completely inter-plumbed, controls are inter-wired)
  • Steam: 40°F or 70°F rise
  • Electric: 40-70°F rise (built-in only)
• Cantilever sideloader (with or without hood) for 90° load operation
  • 24" Sideload
  • 30" Sideload (accepts sheet pans)
• Splash shields
• Water hammer kit (unmounted)
• Drain tempering kit (unmounted)
• 48" Blower-dryer - steam or electric
• Racks: peg or flat racks (specify type)
• Tank heat: choice of steam coil or electric
• ION scale prevention device (unmounted)
• Model PRO 90 (90° Corner Conveyor Table)
• NEW Champion Ventless Heat Recovery (see spec sheet)
• Vent cowl, stainless steel with 7" stack and locking damper
• Water pressure regulating valve (unmounted) (standard with booster)
• Model RCT 64 or RCT 84 Roller Conveyor Table (See factory for custom length)
• Two-Point electrical connection, separate for machine and booster (Field convertible)
• Table limit switch, unmounted (recommended on all rack conveyor installations) (unmounted)
