Beverage Air BB48HC-1-S Black 2 Solid Door Refrigerated Back Bar Storage Cabinet, 115 Volts
Calculate
- 2023 model, meets the newest EPA and DOE codes.
Beverage Air BB48HC-1-S Specifications
| Number of Kegs | 2 Kegs |
|---|---|
| Interior Construction | Shelves |
| Construction | Stainless and Galvanized Steel |
| Cabinet Type | Storage Cabinets |
| Brand | Beverage Air |
| Refrigerant Type | R-290 |
| Made in | USA |
| Certifications | cULus |
| Door Style | Swing |
| Number of Doors | 2 |
| Control Type | Manual |
| Capacity | 12.4 cu. ft. |
| Color | Stainless Steel |
| Door Type | Solid |
| Sections | 2 |
| Voltage | 115 Volts |
| Width (in) | 48 |
| Height (in) | 34 |
| Depth (in) | 24.5 |
| Weight | 266.00 |
Additional Information on Beverage Air BB48HC-1-S
A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Beverage Air BB48HC-1-S Certifications
cULus
UL (Underwriters Laboratories) approval for the US and Canada
UL
UL has tested representative samples of this product and determined that the product meets specific, defined requirements.
UL EPH
Certifies that the goods conform to public health and environmental quality compatibility requirements.
UL EPH Classified
This product complies with UL EPH standards and meets ANSI/NSF requirements.
UL-Sanitation
This item has been tested and meets the sanitation hazard standards imposed by the Underwriters Laboratories (UL).
Beverage Air BB48HC-1-S Description
The Beverage Air BB48HC-1-S Refrigerated Back Bar Storage Cabinet features a stainless steel exterior finish giving it a classy look that is easy to maintain. This unit is designed for use in a commercial bar and will reliably serve for several years. The interior of this back bar refrigerator has 12.4 cu. ft. of refrigerated space that can hold two ½ kegs.
The reach-in sections have self-closing doors to keep them from being left ajar and come standard with locks for security. Inside each section are two epoxy-coated wire shelves to maximize the usable space. When users need to access multiple items the doors have a stay-open feature. To ensure an airtight seal, the doors feature a magnetic gasket. Products inside this back bar refrigerator can be quickly cooled with the balanced forced-air refrigeration system.
This refrigerator has a self-contained refrigeration system featuring a ¼ HP compressor that puts out 1702 BTU/hr of cooling. It can be ordered on either the right or left to best fit your needs. The epoxy-coated evaporator in this model makes sure that a temperature between 36ºF and 38ºF efficiently and reliably. Full electronic control keeps power consumption and stress on the refrigeration system at a minimum. This unit defrosts automatically with a non-electric system to eliminate downtime while maintaining peak efficiency. To meet all environmental regulations R290 hydrocarbon refrigerant is used.
Power is supplied to the unit with a factory wired 8-foot power cord with a NEMA 5-15P plug set to connect it to a standard outlet that provides 115v/60/1-ph power at 2.5 amps.
Every knickknack has a place in the Beverage Air BB48HC-1-S Refrigerated Back Bar Storage Cabinet, ideal for busy bars in search of storage. This backbar storage cabinet is 34 inches tall, 48 inches wide, and 23.50 inches deep.
- Cabinet Construction
- LED lighting
- Self-closing doors
- Full electronic control
- Field reversible doors
- Galvanized sub-top standard
- Black or stainless steel exterior
- Heavy duty stainless steel floor
- Stay-open feature & lock standard
- Two (2) epoxy coated shelves per section, standard
- Magnetic door gaskets provide positive door sealing
- Interior construction utilizes galvanized steel on walls and ceiling
- Compressor available on left or right, specify at time of unit order
- Refrigeration System
- Epoxy coated evaporator coil
- Automatic, non-electric evaporator
- Balanced forced-air refrigeration system provides rapid chilling of product
- Refrigeration system uses R290 refrigerant to comply with all environmental concerns
- Options & Accessories
- Glass door
- Wine racks
- 2” Stainless steel top
- Foot pedal door opener
- 3”-6” casters or 6” legs
- Wine model (40º-60º models)
- Pass-thru & food rated models available
- Electrical Connection
- Units pre-wired at factory and include 8’ long cord and plug set.
