Vulcan VC55GD Double Deck Gas Convection Oven with Digital Contols, 120 Volts
MPN#: VC55GD-QS-PLATINUM
Photo may not represent the actual product.
Always refer to the description and spec sheet (if available).
Free Freight?
Quick Ship
Energy Star ?Products with Energy Star certification are designed to be more energy-efficient to maximize savings.
$11,236.00
Lowest Price Guarantee
Chat Now
Chat Now
Product Protection
Starting at
- Please see specification sheet for installation clearance requirements
Vulcan VC55GD-QS-PLATINUM Accessories
Vulcan RACK HANGRV Rack Hanger
$161.00
Description
Vulcan VC55GD-QS-PLATINUM Description
(Quick Ship) Convection Commercial Oven, gas, double-deck, standard depth, solid state controls, electronic spark ignition, 5-hour timer with digital display enhancement, 150° to 500°F temperature range, (5) oven racks per deck, independently operated removable doors with windows, porcelain on steel interior, interior light, stainless steel front, top, sides & 8"H legs, (2) 1/2 HP blower motors, (2) 50,000 BTU, NSF, CSA Star, CSA Flame, ENERGY STAR®
Convection Oven, gas, double-deck, standard depth, solid state controls, electronic spark ignition, 5-hour timer with digital display enhancement, 150° to 500°F temperature range, (5) oven racks per deck, independently operated removable doors with windows, porcelain on steel interior, interior light, stainless steel front, top, & sides, 8" stainless steel legs, (2) 1/2 HP blower motors, (2) 50,000 BTU, NSF, CSA Star, CSA Flame, ENERGY STAR®, Commercial Convection Ovens
Standard Features
- Painted legs.
- 50,000 BTU/hr. burner.
- Electronic spark igniter.
- Cool-to-the-touch handles.
- Stainless steel front, sides and top.
- Three year limited warranty on doors.
- Oven cool switch for rapid cool down.
- Porcelain enamel on steel oven interior.
- On-board diagnostics for easy servicing.
- One year limited parts and labor warranty.
- 5-hour timer with digital display enhancement.
- Five nickel plated grab-and-go oven racks with eleven rack positions.
- Independently operated lift-off stainless steel doors with double pane windows.
- 1⁄2 H.P. two speed oven blower-motor. 120/60/1 with 6' cord and plug. 7.7 amps total draw.
- 3⁄4" rear gas connection with combination gas valve / pressure regulator and safety solenoid system.
Options
- Casters.
- Stainless steel legs.
- Second year extended limited parts and labor warranty.
Accessoies
- Rack hanger.
- Extra oven rack(s).
- Stainless steel drip pan.
- Down draft flue diverter for direct vent connection.
- Flexible gas hose with quick disconnect and restraining device. Consult price book for available sizes.
Specifications
Double section gas convection oven, Vulcan Model No. VC55GD. Stainless steel front, sides, top and legs. Independently operated stainless steel doors with double pane windows. Non-sag insulation applied to the top, rear, sides, bottom and doors. Porcelain enamel on steel oven interiors measures 29"w x 22 1⁄8"d x 20"h. One interior oven light per section. Five nickel plated oven racks per section measure 28 1⁄4" x 20 1⁄2" with grab-and-go front cut out. Eleven position nickel plated rack guides with positive rack stops. One 50,000 BTU/hr. burner per section. 100,000 total BTU/hr. Electronic spark igniters. Furnished with a two speed 1⁄2 H.P. oven blower motor per section. Oven cool switch for rapid cool down. 120 volt, 60 Hz, 1 ph power supply required. 6' cord and plug. 7.7 amps total draw per section. CSA design certified. NSF listed.
Q & A
Videos
NOTE! This is a general product line video and does not necessarily reflect the listed model.
Vulcan VC55GD-QS-PLATINUM Specifications
| Total BTU | 25000 - 53000 |
|---|---|
| Control Type | Digital |
| Deck | Double |
| Installation Type | Freestanding |
| Oven Interior Style | Standard Depth |
| Brand | Vulcan |
| Energy Efficiency | Energy Star |
| Made in | USA |
| Certifications | NSF |
| Power Type | Gas |
| Size | Full |
| BTU | 50,000 BTU |
| Voltage | 120 Volts |
| Width (in) | 40.13 |
| Height (in) | 68.63 |
| Depth (in) | 40.1 |
| Weight | 778.00 |
Additional Information on Vulcan VC55GD-QS-PLATINUM
Vulcan VC55GD-QS-PLATINUM Certifications
NSF
This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.
