Star UM1854 Ultra-Max® Impingement Conveyor Oven
MPN#: UM1854
1/3
Free Freight?
Quick Ship
$18,865.00 /
Sign-In here for more information
Calculate
Product Protection
Starting at
- Please see specification sheet for installation clearance requirements
Star UM1854 Specifications
| Total BTU | 40000 - 110000 BTU |
|---|---|
| Heating Style | Impingement |
| Belt Length | Standard |
| Belt Width | Standard |
| Production | Standard |
| Brand | Star |
| Made in | USA |
| Certifications | 5-15P |
| Power Type | Gas |
| BTU | 40,000 BTU |
| Number of Belts | 1 |
| Voltage | 120 Volts |
| Width (in) | 60.6 |
| Height (in) | 23.3 |
| Depth (in) | 39.3 |
| Weight | 352.00 |
Additional Information on Star UM1854
middleby-financial-flyer.pdf
warranty-sheet.pdf
installation-operation.pdf
star-um1854.specsheet.pdf
stacking-detail.pdf
diagram.pdf A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Star UM1854 Certifications
5-15P
Two-pole with ground pin plug
cULus
UL (Underwriters Laboratories) approval for the US and Canada
UL
UL has tested representative samples of this product and determined that the product meets specific, defined requirements.
UL EPH
Certifies that the goods conform to public health and environmental quality compatibility requirements.
UL EPH Classified
This product complies with UL EPH standards and meets ANSI/NSF requirements.
Star UM1854 Description
Ultra-Max® Impingement Conveyor Oven, gas, countertop, single deck, 54" conveyor length, 18" wide x 28" length cook chamber, programmable controls for (6) menu presets, conveyor left-to-right standard, field convertible for right-to left, stainless steel bake chamber with easy-to-clean impingement fingers, stainless steel construction, 40,000 BTU, 120v/60/1-ph, 0.5 amps, cord, NEMA 5-15P, cULus, UL EPH Classified, Made in USA
Standard Features:
- Powerful 40,000 BTU stainless steel burner
- Easy to use electronic controls with LED display
- Space saving design allows stacking of two ovens when using either optional legs or stand with casters
- Auxiliary fan pulls in outside air to cool control box keeping key components cooler resulting in longer life
- Heavy-duty Conveyor Oven with drop-down style stainless steel door for easy product access and nozzle plate access
- 18" (0.46 m) wide, 54" (1.37 m) long stainless steel conveyor belt, 28" (0.71 m) cooking chamber, and adjustable 3.5" (89 mm) product openings accommodate a wide variety of products
- Note: More Restaurant Equipment, Cooking Equipment & Commercial Ovens are available.
Options & Accessories
- Nozzle plates
- 4" (102 mm) leg kit
- 6" (152 mm) input shelf
- 8" (203 mm) output shelf
- 10.5" (267 mm) output shelf
- 8" (203 mm) output shelf with drop
- Stand with casters for single or double-stacked oven
